Nonlinear Active Earth Pressure Distribution Based on Coulomb's Theory

Abstract:

On the basis of coulomb’s concept that the active earth pressure against the back of a retaining wall is due to the thrust force exerted by a sliding wedge of soil between the back of the wall and a plane which passes through the bottom edge of the wall and has an inclination of θ, two basis differential equations of first order are set up by considering the equilibrium of the forces and the moments on a partial wedge of soil. The distributing coefficient of active earth pressure is obtained through comparing two basis equations. The unit earth pressure and the application point of the resultant force are deduced. The effects of parameters such as the internal frictional angle of backfill, the frictional angle between the wall back and the backfill, slope angle of filling and dip angle of wall back on distributing coefficient of active earth pressure, the unit earth pressure, the application point of the resultant force, rupture angle are analyzed in detail. Meanwhile the non-linear distributing features are concluded.

• Periodical: Applied Mechanics and Materials (Volumes 90-93)
• Pages: 433-437
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.90-93.433
• Online since: September 2011
• Authors: Jian Gong Chen, Mei Lin Deng, Yong Xing Zhang
• Keywords: Active Earth Pressure, Coulomb's Formula, Distribution, Plane Slip Surface, Point of Application, Retaining Wall

References

[1] Rankine, W. J. M. On the mathematical theory of the stability of earthwork and masonry. Proceedings of the Royal Society of London 8, 1857: 60-61.

[2] Coulomb, C.A. Essai sur une application des regles de maximis et minimisa quelqes de stratique relatifs a l' architecture. In: Memoires de mathematique et de physique. Presentes a l' academie royale des sciences, Paris 7,1776: 343–382.

DOI: 10.1051/geotech/2023019

[3] Caquot, A., Kerisel, F. Tables for the Calculation of Passive Pressure, Active Pressure and Bearing Capacity of Foundations. Gauthier-Villars, Paris; 1948.

[4] Sokolovskii, V.V. Statics of Granular Media. Pergamon Press, New York; 1965.

[5] Lee, I.K., Herrington, J.R. A theoretical study of the pressure acting on a rigid wall by sloping earth or rock fill. Geotechnique 1972; 22 (1): 1–27.

[6] Hua, Z.K., Shen, C.K. Lateral earth pressure on retaining structure with anchor plates. Journal of Geotechnical Engineering , 1987; 113 (3):189–201.

DOI: 10.1061/(asce)0733-9410(1987)113:3(189)

[7] Ernesto M. Generalized Coulomb active-earth pressure for distanced surcharge. J Geotech Eng 1994;120(6):1072–9.

DOI: 10.1061/(asce)0733-9410(1994)120:6(1072)

[8] Fang Y S,Ishibashi I. Static earth pressures with various wall movements[J]. Journal of Geotechnical Engineering, ASCE 1986; 112 (3) : 317 - 333.

DOI: 10.1061/(asce)0733-9410(1986)112:3(317)

[9] Tsinker G P. Handbook of Port and Harbor Engineering- Geotechnical and Structural Aspects [ M]. New York: Chapman & Hall, I (T) P International Thomson Publishing, 1997.

[10] WANG Yuan-zhan. Distribution of earth pressure on a retaining wall[J]. Geotechnique 2000 50(1) :83- 88.
