A Detection System of Impurity in Transparent Liquid

Abstract:

In the fields of transparent liquid impurity detection based on machine vision technology, how to effectively detect impurities in the liquid is a difficult problem which has not yet been solved, mainly in the low recognition rate, the slow recognition speed, and the phenomenon of error detection and undetected. Therefore, this paper presents a new impurity detection method. Firstly, the hardware structure of the system is introduced in this paper. Then the flow diagram of impurity detection is presented. Finally, the algorithm of impurity detection is studied. Experiments show that the system introduced in this paper can identify impurities in liquid well on condition of ensuring the detection speed and detection accuracy.

• Periodical: Advanced Materials Research (Volume 1003)
• Pages: 193-197
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1003.193
• Online since: July 2014
• Authors: Bin Huang*, Ping Wang, Si Le Ma
• Keywords: Algorithm of Impurity Detection, Hardware Structure, Impurity Detection, Machine Vision

References

[1] State Pharmacopeia Committee of China. Pharmacopoeia of the People's Republic of China [M]. Version 2. Beijing: Chemical Industry Press, 2005. (In Chinese).

[2] Xingui Huang. Technical Measures to Improve Packing Quality of Bottled Liquor [J]. Liquor-making Science & Technolosy, 2006, 143(5): 65-66. (In Chinese).

[3] Xudong Sun, Donghai Han. Food Safety &Detective Technology [J]. Global Food Industry, 2006, 1: 49-52. (In Chinese).

[4] Fugang Yang, Tongjing Sun, Songlin Song. Research on key technology of automatic pharmaceutical container inspection machine based on machine vision [J]. Chinese Journal of Scientific Instrument, 2008, 29(3): 562-566. (In Chinese).

[5] H. Yamazaki, T. Katane, H. Fukuda, etc. Inspection device and system for inspecting foreign matters in a liquid filled transparent container[P]. USA, 6937339, (2005).

[6] Fugang Yang, Tongjing Sun, Songlin Song. Artificial Immune Algorithm Based Particle Detection Method for Liquid in Pharmaceutical Container [J] Journal of Electronic Measurement and Instrument，2008, 22(1): 20-24. (In Chinese).

[7] Hui Zhang, Yaonan Wang, Bowen Zhou, etc. Development of healthy wine visible particle detection system based on machine vision [J]. Chinese Journal of Scientific Instrument, 2009, 30(5): 973-979. (In Chinese).

[8] Liang Wang. Study on the System of Filling Quality Monitoring of Beer Using Machine Vision [D]. Jiangsu University, 2009. (In Chinese).

[9] Kena Wang, Yaonan Wang, Juan Lu, etc. Research on the Detection and the Recognition System of Impurity in Transfusion Solution Based on Cam shift Algorithm and SVM [J]. Journal of Hunan University(Natural Sciences), 2009, 36(7): 41-45. (In Chinese).

[10] Weiqiang Yang. The Develop of the Detection System for Visual Foreign Substance Based on Image Sequence [D]. Wuhan University of Technology, 2010. (In Chinese).

[11] Huanjun Liu. Research on liquid intelligent inspection system using machine vision [J]. Computer Engineering and Applications，2010, 46(24)：26-29. (In Chinese).
