Fracture Analysis of Pneumatic Control Valve Rod Used for Nuclear Power Plants

Abstract:

The fracture of a carbon steel pneumatic control valve rod used for Nuclear Power Plants was analyzed in terms of the microstructure, inclusions and fractogragh by means of tensile test, charpy V-Notch impact test, optical microscopy, scanning electron microscopy and energy dispersive spectroscopy. The results indicated that the fracture of the rod is induced by the unqualified chemical composition: a large number of inclusions which distribute in grain boundaries reduce the material plasticity and toughness, and eventually cause fracture.

• Periodical: Advanced Materials Research (Volumes 1004-1005)
• Pages: 1359-1364
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1004-1005.1359
• Online since: August 2014
• Authors: Lei Yang, Yan Li*, Lu Zhang, Yun Ting Lai, Zhi Feng Luo, Wei Wei Yu
• Keywords: Fracture, Inclusion, Microstructure, Nuclear Power Plant (NPP), Pneumatic Control Valve Rod

References

[1] J.P. Ma, J. Jiang: Progress in nuclear energy vol. 53 (2011), p.255.

[2] C.L. Wang, Y.X. Cui, Ar. Voloshin: Engineering Failure Analysis Vol. 9 (2002), pp.493-494.

[3] D.L. Shu: Mechanical property of engineering materials (China Machine Press, China 2003). In Chinese.

[4] Z.W. Wang, Q.N. Fei, W. Mei, C. Wan, L. Yu: Heat Treatment of Metals Vol. 36 (2003), p.22.

[5] F. Nasirpouri, H. Alizadeh, M. Hosseingholizaded: Engineering Failure Analysis Vol. 18(2011), p.2323.

[6] C.B. Liu, S.L. Jiang, Y.G. Zheng: Engineering Failure Analysis Vol. 22 (2012), pp.8-10.
