Physical Simulation Study on Transverse Effect of Bolted Discontinuous Rock Mass

Abstract:

In order to illustrate the mechanism of supporting, maintain the safety and keep the stable of underground projects, it is of great significance to study the transverse effect of bolted discontinuous rock mass. With a 3D model and corresponding physical simulation, analyzing the testing results of the bolt stress, rock stress and displacement discovers some new findings. Besides its reinforcing effect to the rock mass, the bolt has a negative effect on the discontinuous rock mass by its so-called ‘railway effect’ under shear loading. The finding of this bolt function will help to further understand of bolting mechanism and it is very important to raise the safety of bolt supporting design. Furthermore the effect grade is a positive correlativity with the bolt diameter, and the shear displacement is one of its necessary conditions.

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 1292-1296
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.1292
• Online since: August 2014
• Authors: Ying Xuan Jia*, Hong Wei Song, Gui Zhang, Xing Kuang
• Keywords: Bolt Supporting, Discontinuous Rock Mass, Physical Simulation, Transverse Effect
