10KW/100KHZ High Frequency Induction Heating Power Supply Design

Abstract:

TMS320F2812 was taken as the main controlling chip, MOSFET was taken as the inverter switching device and IGBT was taken as the chopper switching device in the system. This paper introduced the main topology circuit design and circuit components selection.In the process of heating, double-closed loop control strategy fuzzy and DPLL (Digital Phase Locked Loop) was adopted. The simulation model of induction heating power system was built in SIMULINK platform. The simulation results indicate that the load frequency automatic tracking and closed-loop power control are realized. The time to steady output is about 0.1ms. Finally, built the 10kW/100kHZ induction heating power supply experimental platform, As can be seen from the experimental waveforms, the equivalent impedance of the load can always be weakly perceptual state.

• Periodical: Advanced Materials Research (Volumes 1008-1009)
• Pages: 637-640
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1008-1009.637
• Online since: August 2014
• Authors: Mei Lan Zhou*, Yan Ping Li, Ji Chang Wang
• Keywords: DPLL, Frequency Automatic Tracking, Induction Heating, Power Supply

References

[1] Jiaxi Hu, Lijun Zhao, Quanchong Hu: Power Technology, 2013(37): 25-38. (In Chinese).

[2] Xingzhe Piao, Song Yang, YuShan Xue: Power Journal, 2013(3): 276-280. (In Chinese).

[3] Hui Cai, Rongxing Zhao, Huiming Chen: Proceedings of the CSEE, 2006(2): 67-69. (In Chinese).

[4] Meilan Zhou, Zeqing Xu, Yanping Li: International Conference on Measurement Information and Control (ICMIC), 2013: 1000-1003.

[5] T . Akisawa, M. Miynamae: Electrical Machines and Systems (ICEMS), 2013: 1630-1634.

[6] Zongpu Yang, Shuzhong Song, Jianwei Ma: Power Electronic Technology, 2010(9): 44-45. (In Chinese).
