Research on the Remaining Oil Starting Mechanism in Different Pores of Polymer Surfactants Using NMR Analysis

Abstract:

With its unique structure and properties, polymer surfactants have been used in chemical flooding. Compared with ordinary polymer, polymer surfactants have a higher recovery degree. However, remaining oil starting mechanism in different pores using different polymer surfactants after water flooding is still unclear. NMR (Nuclear Magnetic Resonance) has a good effect on determination of rock oil saturation and analysis of pore structure. In this paper, oil displacement experiment using kerosene which contains no hydrogen was conducted and the problem caused by the similarity between oil phase relaxation time and water relaxation time in large pores was overcome. Through the change of NMR relaxation time, oil distribution situation in different pores of ordinary polymer, refining III polymer surfactant, and Haibo III polymer surfactant after polymer flooding was measured accurately. This paper also quantitatively analyzed the contribution degree to oil recovery in pores of different sizes, and evaluated oil displacement effect of the above three kinds of oil displacement systems. The results show that when only the swept volume is considered, recovery degree of Haibo III polymer surfactant is higher, reaching 53.66%. In different systems, middle pores contribute most to recovery degree. At the same time, the remaining oil in middle pores and large pores accounts more, which is the main attack direction towards tapping the potential of remaining oil in the oilfield.

• Periodical: Advanced Materials Research (Volumes 1010-1012)
• Pages: 1727-1734
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1010-1012.1727
• Online since: August 2014
• Authors: Yi Qiang Li, Zhe Yu Liu*, Yan Yue Li, Yi Bo Xu
• Keywords: NMR (Nuclear Magnetic Resonance), Polymer Surfactants, Remaining Oil, Starting Mechanism

References

[1] Lei Wang. Study on EOR Mechanism and Influencing Factors of polymer surfactants [D]. Daqing: Daqing Petroleum Institute, 2010. In Chinese.

[2] Gongjian Guo, Changchun Gu. Oil Saturation in Rock Cuttings Measured by Nuclear Magnetic Resonance [J]. Chinese Journal of Magnetic Resonance, 2005, 22 (1): 67-72. In Chinese.

[3] Zhentao Li. Using Two Dimensional NMR Technology to Research Core oi1 Saturation [D]. Beijing: Graduate University of Chinese Academy of Sciences, 2011. In Chinese.

[4] Kevin Munn, Douglas M Smith. A NMR Technique for the Analysis of Pore Structure: Numerical Inversion of Relaxation Measurements [J]. J Colloid Interf Sci, 1987, 19 (1): 117-126.

DOI: 10.1016/0021-9797(87)90250-5

[5] Qimin Wang. Practice and Understanding of Polymer Oil Flooding Technology [J]. Daqing Petroleum Geology and Development, 1999, 18 (4): 1~5. In Chinese.

[6] C. H. Arns, K. E. Washburn, and P. T. Callaghan. Multidimensional NMR in Verse Laplace Spectroscopy in Petro Physics [J]. SPWLA 47th Annual Logging Symposium, June 4-7, 2006.

[7] Yaakov et al. A practical approach to obtain primary drainage capillary pressure curves from NMR core and log data. Petro physics, 2001, 42(4): 334～343.

[8] Robin Au brooks. Pore-size distribution in muggy carbonates from core. SPE Annual Technical Conference and Exhibition held in Houston, Texas, 1999, 139～152.

[9] Guobo Gong, Boqin Sun etal. NMR Relaxation of the Fluid in Rock Porous Media [J]. Chinese Journal of Magnetic Resonance, 2006, 23 (3): 380-383. In Chinese.

[10] Zhao Jiang. Study on Oil Physical Flooding Simulation Experiment of LianHua and HaiBo Polymer Surfactants [D]. Daqing: Daqing Petroleum Institute, 2012. In Chinese.

[11] Luna. Study on the Properties of Refining and Haibo Polymer Surfactant System [D]. Daqing: Daqing Petroleum Institute, 2012. In Chinese.
