Improvement Design of the Insulation Structure of High Temperature Pneumatic Duct System of the Aircraft

Abstract:

Based on the study of the duct leak detection system of commercial aircraft in existence, the insulation structure of high temperature pneumatic duct system of the aircraft is improved with multilayer insulation method and its engineering calculation method is derived. Also, the insulation experiment platform of the high temperature pneumatic duct system is built to verify the applicability and feasibility of the engineering calculation method. The research result shows that the results from the engineering calculation method is not fit the experimental data perfectly, the margin of error is 17 percentage. The main reason is that the diversion tunnels has a little effect on the temperature distribution and in these cases parameter modification method should be adopted in the engineering calculation method. These works would be helpful for the design and optimization of the high temperature pneumatic duct system.

• Periodical: Advanced Materials Research (Volume 1016)
• Pages: 423-428
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1016.423
• Online since: August 2014
• Authors: Hong Shi*, Yan Long Jiang, Yin Peng, Yu Fei Cai
• Keywords: Aircraft, High Temperature Pneumatic Duct System, Leak Detection System, Multi-Layer Insulation, Thermal Insulation

References

[1] The Engineering Society for Advancing Mobility Land Sea Air and Space, SAE ARP699, High Temperature Pneumatic Duct Systems for Aircraft[S], (1997).

[2] The Engineering Society for Advancing Mobility Land Sea Air and Space, SAE AS1960, Coupling Assembly, V-Band, Sheet Metal Flange, Pneumatic Tube[S], (2007).

[3] The Engineering Society for Advancing Mobility Land Sea Air and Space, SAE AS1895, Flange End , Male, Type I Standard, Profile Design Standard [S], (2007).

[4] Radio Technical Commission for Aeronautics, RTCA/DO-160E, Environmental Conditions and Test Procedures for Airborne Equipment [S], (1997).

[5] Brake Daniel E., Stearns Steven V., Ronsky N. Dary. Enhanced pipeline leak detection using airborne differential absorption LIDAR[R]. Proceedings of the Biennial International Pipeline Conference, 2008, v2: 941-948.

DOI: 10.1115/ipc2008-64650

[6] Chyr Pyng Liou. Pipeline leak detection and location[R]. Pipeline Design and Installation: Proceedings of the International Conference, 1990: 255-269.

[7] CRJ700/900 AMM (Aircraft Maintenance Manual) [Z]. Bombardier Inc. Revision 33. (2010).

[8] CRJ100/200 AMM (Aircraft Maintenance Manual) [Z], Bombardier Inc. Revision 14, (2006).
