Robust H_∞ Fuzzy Control for Nonlinear Networked Control System and its Application

Abstract:

The paper studies the effect of networks with transmission delay in the feedback loop of a nonlinear networked control system (NCS). The nonlinear system is modeled by a T-S fuzzy model, and transmission delays are modeled by a finite state Markov process. The fuzzy controller’s membership functions can be different from the plant’s. The membership functions of the plant and the fuzzy controller are incorporated into the controller design. System performance is measured via an norm from disturbance to error and the controller is computed by sum of square approach. Finally we applied these results to an inverted pendulum system. Theoretical analysis and simulation results show that the control strategy studied in this paper is effective and feasible.

• Periodical: Advanced Materials Research (Volume 1022)
• Pages: 406-410
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1022.406
• Online since: August 2014
• Authors: Qing Feng Wang*, Hong Bo Wang
• Keywords: Fuzzy Control, Networked Control System (NCS), Nonlinear System, Transmission Delay

References

[1] J. Nilsson: Real-time control systems with delays, Ph.D. dissertation. Dept. Automatic Control, Lund Inst. Technology, Lund, Sweden (1998).

[2] H. Zhang, M. Li, J. Yang, D. Yang: Fuzzy model-based robust networked control for a class of nonlinear systems, in: IEEE Transactions on Systems, Man and Cybernetics, Part A: Systems and Humans, vol. 39, no. 2(2009), pp.437-447.

DOI: 10.1109/tsmca.2008.2010787

[3] M. Mahmoud: Control of Uncertain Fuzzy Networked Control Systems with State Quantization, in: Intelligent Control and Automation, Vol. 3 No. 1(2012), pp.59-70. (2012).

DOI: 10.4236/ica.2012.31008

[4] S. K. Nguang: Comments on Fuzzy Tracking control for nonlinear networked control systems in T-S fuzzy model, in: IEEE Trans. Syst. Man Cybern.B. Cybern, Vol. 40, No. 3, (2010), pp.957-957.

DOI: 10.1109/tsmcb.2009.2030883

[5] C. Peng, T.C. Yang: Communication-delay-distribution-dependent networked control for a class of T-S fuzzy systems, in: IEEE Transactions on Fuzzy Systems, vol. 18, no. 2(2010), pp.326-335.

DOI: 10.1109/tfuzz.2010.2041354

[6] X. Jiang and Q.L. Han: On designing fuzzy controllers for a class of nonlinear networked control systems, in: IEEE Transactions on Fuzzy Systems, vol. 16, no. 4(2008), pp.1050-1060.

DOI: 10.1109/tfuzz.2008.917293

[7] A. Papachristodoulou and S. Prajna: A tutorial on sum of squares techniques for systems analysis, in: American Control Conference, vol. 4(2005), p.2686–2700.

DOI: 10.1109/acc.2005.1470374

[8] Seunghwan Chae, Sing Kiong Nguang and Wenqin Wang: Robust fuzzy control of discrete nonlinear networked control systems: a SOS approach, in: Journal of the Franklin Institue(2014).

DOI: 10.1109/tcyb.2013.2281458

[9] Qingfeng Wang, Hong Chen, Ping Wang: Design and Implementation of Simulation Platform for Networked Control Systems Based on NS2, In: Journal of system simulation, Vol. 23, No. 2 (2011), pp.271-276.

[10] Fei Han, Gang Feng, Yong Wang, et al: A novel dropout compensation scheme for control of networked T-S fuzzy dynamic systems, in: Fuzzy sets and systems, 235(201), pp.44-61.

DOI: 10.1016/j.fss.2013.05.011
