Design of Pressurized Vaulted Rectangular Conduits Using the Rough Model Method (Part 2)

Abstract:

The problem of calculating the diameter of a pressurized vaulted rectangular conduit is solved explicitly through two methods which are based on an referential rough model whose geometric and hydraulic characteristics are well defined. The first method provides a highly reliable approximate relation which gives very accurate results for all practical applications. The second method consists in introducing into the calculations a rectangular rough model whose geometric and hydraulic properties were judiciously chosen. The theoretical development leads to an equation of third degree whose resolution has been made possible by the hyperbolic and trigonometric functions. Practical examples are presented to explain the procedure of calculation.

• Periodical: Advanced Materials Research (Volumes 1025-1026)
• Pages: 24-31
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1025-1026.24
• Online since: September 2014
• Authors: Bachir Achour*, Mohammed Khattaoui
• Keywords: Discharge, Energy Slope, Pressurized Conduit, Rough Model Method, Turbulent Flow, Vaulted Rectangular Conduit

References

[1] V.T. Chow: Open-Channel Hydraulics, McGraw Hill (1973).

[2] H. Darcy : Comptes rendus des séances de l'Académie des Sciences Vol. 38, No. 5 (1954), p.1109.

[3] C.F. Colebrook: J. Inst. Civil. Eng. Vol. 11, No. 2 (1939), p.133.

[4] R.O. Sinniger and W.H. Hager: Constructions hydrauliques, Presses Polytechniques Romandes (1989).

[5] P.K. Swamee and N. Swamee: J. Hyd. Res. Vol. 46, No. 2 (2008), p.277.

[6] P.K. Swamee and A.K. Jain: J. Hyd. Eng. Vol. 102, No. HY5 (1976), p.657.

[7] B. Achour: Adv. Mat. Res. Vol. 779-780 (2013), p.414.

[8] B. Achour, A. Bedjaoui : J. Civil Eng. Sci. Vol. 1, No. 1 (2012), p.36.

[9] B. Achour, A. Bedjaoui: J. Hyd. Res. Vol. 44, No. 5 (2006), p.715.
