Finite Element Analysis of the Fine Blanking Process for Seat Recliner Plate Holder of Recreation Vehicle

Abstract:

In this paper, the finite element analysis (FEA) of the fine blanking process was conducted for the seat recliner plate holder of recreation vehicle. Because the plate holder was a complex part with the various dimple shapes, it was formed and blanked with a three-station progressive fine blanking tool. The fine blanking tool was optimally designed, manufactured and performed the fine blanking experiments. The shear surface of the outer contour, the stress and strain of the part, and the loads of the tool elements were estimated by the results of the fine blanking simulation. Because the plate holder samples from fine blanking experiments had the good accuracy of the dimples’ position and dimension, it would be noticed the fine blanking simulation was conducted without error.

You might also be interested in these eBooks

Advanced Materials, Structures and Mechanical Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 1025-1026)

Pages:

391-394

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1025-1026.391

Citation:

Cite this paper

Online since:

September 2014

Authors:

Jong Deok Kim*, Young Moo Heo

Keywords:

Dimple Shape, FEA, Fine Blanking, Plate Holder, Shear Surface

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] T. Altan: Metal Forming Handbook, Shuler GmbH, Berlin Heidelberg NewYork, Springer-Verlag (1998).

Google Scholar

[2] K. Lange, F. Birzer, P. Hoefel, A. Muhoty and H. Singer: Cold forging and Fineblanking – A handbook on cold processing, material properties, component design, Buderus Edelstahl (1997).

Google Scholar

[3] F. Birzer: submitted to J. Mater. Res. (2003).

Google Scholar

[4] W. Blatter, in: Introduction into the technology fine blanking tools, Incheon, KAITECH (1991).

Google Scholar

[5] J. D Kim, H. K Kim, Y. M Heo and S. H Chang: A study on die roll height of special automobile seat recliner gear according to die chamfer shape in fine blanking tool, Adv. Mater. Res. Vol. 121-126 (2012), p.3694.

DOI: 10.4028/www.scientific.net/amm.121-126.3694

Google Scholar
