Analytical Models for Determining Rotational Capacity of Clip-Angle Connections under Seismic Loading

Abstract:

This paper explores rotational capacities and demands in thick top-and-seat (cleated) angle partially restrained connections subjected to monotonic and cyclic loads. The results of test on full-scale angle connections are described first, and are then compared to published curve-fitting models for these types of connections. The data indicates that the curve-fitting constants of some existing mathematical models cannot be extrapolated to thick angles. The results indicate that these connections are capable of providing very ductile behavior and constitute an ideal back-up structural system in steel frames.

• Periodical: Advanced Materials Research (Volumes 1025-1026)
• Pages: 979-986
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1025-1026.979
• Online since: September 2014
• Authors: Jong Wan Hu, Hong Min Son*
• Keywords: Analytical Models, Clip-Angle Components, Partially Restrained (PR) Connections, Rotational Capacity

References

[1] J. Liu and A. Astaneh-Asl: J. Struct. Eng. -ASCE. Vol. 126, No. 1 (2000), p.32.

[2] R.T. Leon, J.A. Swanson, C. Schrauben and J. Smallidge: Experimental Test and Analytical Models for Bolted Connections, Final Report MAE Center Project ST-7, Georgia institute of Technology, Atlanta GA (2000).

[3] J.A. Swanson and R.T. Leon: J. Struct. Eng-ASCE. Vol. 126, No. 1 (2002), p.50.

[4] S.L. Chan and P.P.P. Chui: Nonlinear Static and Cyclic Analysis of Steel Frames with Semi-Rigid Connections, Elsevier, Oxford, England (2000).

DOI: 10.1016/b978-008042998-4/50003-x

[5] W.F. Chen and S.E. Kim: LRFD Steel Design using Advanced Analysis, CRC press (2000).

[6] M.J. Frye and G.A. Morris: Canadian. J. Civil. Eng. Vol. 2, No. 3 (1975), p.280.

[7] R.M. Richard and B. J Abbott: J. Eng. Mech-ASCE. Vol. 101, No. 4, (1975), p.511.

[8] K.M. Ang and G.A. Morris: Canadian J. Civil. Eng. Vol. 11 (1984), p.245.

[9] W.F. Chen and N.K. Kishi: J. Struct- ASCE. Vol. 115, No. 1 (1989), p.105.

[10] C.S. Schrauben: MS Thesis, Behavior of Full-Scale Bolted Beam to Column T-stub and Clip Angle Connections Under Cyclic Loading, Georgia Institute of Technology (1999).

[11] J.A. Azizinamini, W.G. Altman and J.B. Radziminski, et al.: Moment-Rotation Characteristics of Semi-Rigid Steel Beam-Column Connections, Earthquake Hazard Mitigation Program, University of South Carolina, Columbia (1982).

[12] W.F. Chen, N. Kishi and K.G. Matsuoka: Eng. J. AISC. 4th quarter (1993), p.90.

[13] S. Seon and J.W. Hu: J. Korean. Soc. Adv. Comp. Struct. Vol. 2 (2011), p.1.

[14] D. K. Kim and J. W. Hu: Adv. Mater. Res. Vol. 650 (2013), p.407.

[15] D. K. Kim and J. W. Hu: Adv. Mater. Res. Vol. 650 (2013), p.667.

[16] J. W. Hu, R. T. Leon and T. Park: ISIJ. Int. Vol. 50, No. 6 (2010), p.883.

[17] J. W. Hu, D. K. Kim, R. T. Leon and E. Choi: ISIJ. Int. Vol. 51, No. 4 (2011), p.619.

[18] J. W. Hu, R. T. Leon and E. Choi: Int. J. Steel. Struct. KSSC Vol. 01, No. 1 (2011), p.1.

[19] J. W. Hu, R. T. Leon and T. Park: J. Constr. Steel Res. Vol. 78 (2012), p.45.

[20] J. W. Hu: Adv. Mater. Res. Vol. 650 (2013), p.379.
