Failure Analysis on the Collapsed Tubing of High Pressure and High Production Gas Well in the Process of Testing and Production

Abstract:

The split, fall, collapse and severe diapirism of tube body happened on one of the tubing used in the gas well of high pressure and high production in the process of the trial extraction. This paper aims to explore the reason of its occurrence through the research of the macroscopic analysis, mechanical and chemical property test and microscopic metallographic test study. The result of the research shows that the multiphase flow of gas, liquid and solid in the tubing may produced an instantaneous negative pressure and increased the possibility of the tubing being collapsed in the process of gas testing and production.Then it resulted in clogging, severe ablation, thinning wall and piercing in tube and finally the tube broke because of the low tensile strength.

• Periodical: Advanced Materials Research (Volume 1035)
• Pages: 198-203
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1035.198
• Online since: October 2014
• Authors: Ji Jun Xue, Bin Zhao*, He Zhao
• Keywords: Ablation, Gas Well of High Pressure, High Production, Tensile Strength, Tubing

References

[1] Zhang Jianbing, Liu Xinying, Lv Xianghong. Finite Element Calculation of Casing Collapsing Strength Geometric Modeling Parameters [J]. Journal of Petroleum Machinery, 2009, 5 (10) : 69 ~ 72.

[2] Sun Yongxing. For Oil and Gas Well Tubing, Casing ISO New Collapsing Model [J]. Journal of Natural Gas Industry, 2009, 29 (12) : 32 ~ 34.

[3] Hu Wenping, Zhang Laibin, Fan Jianchun. Casing Collapse Question Research Present Situation and Development Tendency[J]. Oil Field Machinery, 2006, 35 (5) : 1 ~ 4.

[4] Wu Jianguo. Reverse Circulation Kill Squish Pipe Stress Analysis and Calculation[J]. Journal of Natural Gas Industry, 1995, 15 (3) : 85 ~ 86.

[5] Lou Qi, Zhang Guanglu, Zhang Dan, Han Xinli and Yang Peng, The Main Factors Influencing Casing Collapsing Strength Experimental Study[J], Oil Field Machinery, 2012, 9 (6) : 38 to 42.

[6] Huang X, Mihsein M, Kibble K, etal. Collapse Strength Analysis of Casing Design Using Finite Element Method[J]. International Journal of Pressure Vessels and Piping. 2000(77): 359~367.

DOI: 10.1016/s0308-0161(00)00045-4

[7] Wang Jing, Gas and Liquid Phase Flow Dynamic Characteristics Research[M], Shanghai: Shanghai Jiaotong University Press, 2012. 2 ~ 4.

[8] Han Zhiyong, The Collapsing Strength of Casing String Triaxial Design Discussion [J]. Journal of University of Petroleum(national academy), 2004, 28(5): 43~48.
