Study on Walking System Technology of Crawler Combine Harvester

Abstract:

Crawler combine harvester walking system is various transmission technology are organic and reasonable matching, foster strengths and circumvent weaknesses, complementary drive system so as to achieve the best overall. Stepless speed walking is particularly suitable for complex condition changes, the demand of drive system for a more comprehensive, more comprehensive, objective stepless speed walking in transmission system innovation or seek better performance, and as a mechanical transmission device of the planetary gear has the advantages of small volume transfer large torque, high efficiency. The combination of both realizes stepless transmission, and has the advantages of low speed and high torque. Hydraulic drive system is mainly to achieve stepless speed regulation, commutation, planetary gear drive mainly reduce speed, increase the torque to. Composite transmission mode that can greatly improve the transmission ability, expand the scope of speed adjustment. In fact, combine the stepless variable speed running and control technology can greatly improve the performance of the product, especially the effect on production efficiency, durability, controllability, environment adaptability, green characteristics were significantly.

• Periodical: Advanced Materials Research (Volume 1037)
• Pages: 107-110
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1037.107
• Online since: October 2014
• Authors: Xi Yin Lou*
• Keywords: Composite Transmission, Green Characteristics, Mechanical Design, Walking System

References

[1] The Reliability Problem of Rice Combines Outstanding. Http: /www. ransmissionbelt. com.

[2] LOU Xiyin, Model Crawler Self-propelled Walking System Design of Type Combined Harvester Hydraulic Machinery [J] Modern Agricultural Science and Technology, 2012 (5): 262-263.

[3] CAO Fuyi, ZHOU Zhili. Crawler Tractor Hydromechanical Double Power Differential Steering Mechanism design [J]. Journal of Agricultural Machinery, 2006 37 (9): 5~8.

[4] CHEN Fa, WANG Xuenong, SUN Ying, ZHUANG Lijun. 4MZ-2 (3) analysis type cotton picker technology scheme and determine the main transmission system [J]. Journal of Agricultural Engineering , 2001(5): 68~72.

[5] Yuanling, LI Shangping, LI Dahua. Application and Analysis of Hydraulic Technology in Agricultural Machinery [J]. Guangxi Agricultural Machinery, 2003(3): 33~34.

[6] CHEN Yuechun, Matching and Energy Saving Control on Hydrostatic Transmission Tractor Power. Jiangsu: Jiangsu University, (2010).

[7] CHE Yuan, JING Yingzi, FENG Jiang. Study on 4ZTL-1800 Hydraulic System of Combine Harvester for Threshing Prior to Cut [J]. Agricultural Mechanization Research 2001(3): 48~49, 57.

[8] HAN Huixian, CAO Xianli. Tire Crane Walking Simulation and Optimization of Hydraulic System Based on AMESim [J]. Hoisting and Conveying Machinery, 2009 (7): 13~16.

[9] HU Junchi. The Advantages and disadvantages of Closed Hydraulic Transmission System [J]. Fluid Drive and Control, 2011(2): 58~60.
