Single Longitudinal Mode Fiber Laser Based on Saturated Absorber

Abstract:

In order to realize single longitudinal mode (SLM) output, an erbium-doped fiber (EDF) laser with fiber ring cavity is proposed which uses an un-pumped EDF saturated absorber as a SLM selector. Ring cavity length, coupler ratio and insertion loss which affect ring cavity filter performance are analyzed theoretically and simulated numerically. Un-pumped EDF length and Er³⁺ concentration are analyzed theoretically and simulated. Research shows that, the bigger coupling output ratio of ring cavity, the greater transmission peak; the greater mode line width; the shorter ring cavity length, the wider free spectral range; the bigger coupling loss, the smaller transmission peak; when the difference between two cavities length is big, cursor effect is not obvious. Laser threshold increases with absorber length increasing; the bigger saturated absorber concentration, the higher laser threshold.

• Periodical: Advanced Materials Research (Volumes 1044-1045)
• Pages: 426-431
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1044-1045.426
• Online since: October 2014
• Authors: Wu Pan, Hong Lin Zhang, Zheng Ke Xu, Hui Zhang
• Keywords: Fiber Laser, Fiber Ring Cavity, Laser Technology, Single Longitudinal Mode, Un-Pumped EDF

References

[1] ZHANG Xin, CHEN Wei, LIU Yu, et al, Single Longitudinal Mode Fiber Laser with Multiple Ring Cavities and Its Frequency Stabilization, J. CHINESE JOURNAL OF LASERS. 34 (2007) 48-52.

[2] DAI Zhi-yong, ZHANG Xiao-xia, et al, A single-frequency narrow-linewidth fiber laser with PM fiber saturable absorber, J. Journal of Optoelectronics · Laser. 22 (2011) 652-655.

DOI: 10.1109/sopo.2010.5504159

[3] X. P. Cheng, P. Shum, et al, Single-Longitudinal-Mode Erbium-Doped Fiber Ring Laser Based on High Finesse Fiber Bragg Grating Fabry-Perot Etalon, J. IEEE PHOTONICS TECHNOLOGY LETTERS. 20 (2008) 976-978.

DOI: 10.1109/lpt.2008.922974

[4] Fang Xiuli, Tong Zhengrong, Cao Ye, et al, Narrow linewidth ring cavity fiber laser using F-P fiber ring filter, J. Infrared and Laser Engineering. 42 (2013) 329-333.

[5] Jiao Mingxing, Xing Junhong, Tong Congwei, et al, Design and Experimental Study of Two-Wavelength Single-Longitudinal-Mode Erbium-Doped Fiber Ring Laser, J. CHINESE JOURNAL OF LASERS. 40 (2013) 0602013(1-6).

DOI: 10.3788/cjl201340.0602013

[6] Min Yong Jeon, Namje Kim, et al, Widely tunable dual-wavelength Er3+-doped fiber laser for tunable continuous-wave terahertz radiation, J. OPTICS EXPRESS. 18 (2010) 12291-12297.

DOI: 10.1364/oe.18.012291

[7] Zhang Yong, Cao Ye, et al, Wavelength switchable erbium-doped fiber laser based on PSG and feedback optical fiber ring, J. Journal of Tianjin Polytechnic University. 29 (2013) 1-5.

[8] TIAN Yun-yun, FENG Su-juan, MA Yan, et al, A wide-tunable single-longitudinal-mode fiber laser based on compound ring cavity and tunable fiber Bragg grating, J. CHINESE JOURNAL OF QUANTUM ELECTRONICS. 30 (2013) 288-292.

DOI: 10.1109/lpt.2012.2235141

[9] Xu Pan, Hu Zhengliang, Ma Mingxiang, et al, Numerical Simulation and Characteristics Analysis of Saturable Absorber Grating in Fiber Ring Cavity Resonator, J. ACTA OPTICA SINICA. 32 (2012) 0814001(1-7).

DOI: 10.3788/aos201232.0814001

[10] CAO Ye, JIA Guo-qiang, ZHAO Jun-fa, et al, Dual-wavelength single longitudinal-mode erbium-doped fiber lasers based on feedback fiber ring, J. Journal of Optoelectronics · Laser. 24 (2013) 833-837.

DOI: 10.1088/1054-660x/24/1/015104

[11] Zhang Yan, Chen Wei, Ren Min, et al, Stable, Tunable Single-Longitudinal-Mode Erbium-doped Fiber Laser with Multiple Ring Cavities, J. ACTA OPTICA SINICA. 28 (2008) 507-511.

DOI: 10.3788/aos20082803.0507
