A Control Strategy with Series-Parallel Inverter for Micro-Grid Operation

Abstract:

For the different operation mode of micro-grid, an improved droop control method and a parallel inverter was proposed depending on the study of micro-grid inverter. Grid-connected interface contains a series inverter and a parallel inverter, and can be switched to select different work mode. The parallel inverter can eliminate harmonic, compensate three-phase imbalanced current to improve the quality of the power delivered to the utility grid. In islanding operation mode, the improved droop control strategy was applied, where an integral controller was introduced. So it can reduce the inverter output voltage amplitude. Thereby it can restrain circulation and realize the power of self-distribution. The effectiveness and feasibility are verified by the simulation result.

• Periodical: Advanced Materials Research (Volumes 1044-1045)
• Pages: 677-680
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1044-1045.677
• Online since: October 2014
• Authors: Gui Ying Liu, Yong Guang Gui*, Shi Ping Su, Qian Luo, Jiang Wu, Xue Rui Jia
• Keywords: Circulation Suppression, Droop Control, Harmonic, Microgrids (MGs), Series-Parallel Inverter

References

[1] S. Mishra, D. Ramasubramanian, P.C. Sekhar, A Semless Control Methodology for a Grid-connected and Isolated PV-Diesel Microgrid[J]. IEEE Transactions on Power System, 2013, Vol. 28, No. 4: 4393-4404.

DOI: 10.1109/tpwrs.2013.2261098

[2] Claudio A. Cañizares. Trends in Microgrid Control[J]. IEEE Transactions on smart grid, 2014, Vol. 5, No. 4: 1905-1919.

[3] Zheng Jinghong, Wang Yanting, Li Xingwang, etal. Control methods and strategies of microgrid smooth swetchover[J]. Automation of Electric Power Systems, 2011, Vol. 35, No. 18: 17-24.

[4] ZHANG Guorong, ZHANG Tieliang, Ding Ming, etal．Simulation research on unified Power Quality conditioner with PV grid connected generation[J]．Proceedings of the CSEE, 2007, Vol. 27, No. 7: 82-86.

[5] Xu Ruilin, Xu Xin, Zhen Yongwei, et al. Improved droop control scheme for microgrid operation[J]．Proceedings of the EPSA, 2012, Vol. 24, No. 6：15-19.

[6] Hu Xiaoqing, Chen Qiming, Bai Yuanfei, etal. Application of energy storage units based on tricyclic feedback decoupling control strategy in wind-solar hybrid microgrid system[J]. Power System Protection and Control, 2013, Vol. 41, No. 13, 97-103.

[7] Josep M. Guerrero, Nestor Berbel, Jose Matas, et al, et al．Decentralized control for parallel operation distributed generation inverters using resistive output impedance．IEEE transactions industrial electronics, 2007, Vol. 54, No. 2: 994-1004.

DOI: 10.1109/tie.2007.892621

[8] Jaehong Kim, Josep M. Guerrero, Pedro Rodriguez, et al. Mode Adaptive Droop Control With Virtual Output Impedances for an Inverter-Based Flexible AC Microgrid[J]. IEEE Transactions on Power Electronics, 2011, Vol. 26, No. 3: 689-701.

DOI: 10.1109/tpel.2010.2091685
