Generic and Automatic Multi-Channel Control System

Abstract:

This document mainly describes the control equipment of microwave anechoic chamber RCS measurement system, which can be expanded into a generic and automatic multi-channel control system. The conventional control equipment is mainly operating in manual mode with computer control feature as secondary. Such feature causes the problems of difficult operation, complicated structure and no software portability. This generic control system is designed with DAM-E3000 series of module which is an interface module from generic sensor to computer, uses remote Ethernet connection solution, supports TCP/IP and UDP protocols, and can realize remote I/O control. This generic control system has the automatic control feature through network by using this mentioned module. In addition, the hardware structure design is simplified, and the software portability and expandability are enhanced, so that the codes programming difficulty is lowered. Therefore the system can conform to more industrial I/O signal protocols and can be used widely in various industrial environments.

• Periodical: Advanced Materials Research (Volume 1046)
• Pages: 310-314
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1046.310
• Online since: October 2014
• Authors: Xiao Yu Zhang*, Yuan Wu, Chong Jiang Mo
• Keywords: Automatic Multi-Channel Control System, Control Device, DAM-E3000, Generic Multi-Channel Control System, Long-Distance Control, Microwave Anechoic Chamber, RCS

References

[1] Ruan Yingzheng: Study of scattering characteristics of objects and RCS. Chinese of Journal Electronics Vol. 06 (1990) , pp.92-96.

[2] Guo Jing: Study and test of RCS measuring method in mircowave anechoic chamber. Nanjing University of Aeronautics and Astronautics(2008).
