Four Axis NC Machining Turbine Blade Method Research

Abstract:

The steam turbine blade is one of the important parts of steam turbine, its quality fit and unfit quality directly impact on the performance of steam turbine. Turbine blade has its type surface complex, requiring precision higher and other characteristics, so it was a difficult problem in the field of machinery manufacturing. Therefore, how to adopt appropriate methods to improve the manufacturing quality of blade is of great significance. This paper has discuses the big distortion, the variable cross-section of turbine blade NC machining method, completed numerical control simulation and all the process and post processing in Cimatron E8.5 software environment. For similar modalities surface parts of NC machining provided a good idea.

• Periodical: Advanced Materials Research (Volume 1048)
• Pages: 579-583
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1048.579
• Online since: October 2014
• Authors: Min Kong*, Hai Bo Ji, Xiao Xu Wang
• Keywords: Four Axis Processing, Numerical Simulation, Turbine Blade

References

[1] References in the text: Figure 1, Figures 2-4, 6, 8a, b (not abbreviated).

[2] Jilan Wu, Steam turbine equipment and systems [M]. Beijing: China electric power press, 2006. 5-10.

[3] Jianxin Xu, Jun Hu, Yuhan Wang. Three-dimensional entity digital measurement and the research status of numerical control processing integration technology [J]. Machinery manufacturing, 2002. 40（458）：22-24.

[4] Mingyou Wu. Nc automatic programming—Cimatron E explanation [M]. Tsinghua university press, 2008. 15-16.

[5] Binggen Chen. The application of multiple shaft blank based on Cimatron E [J]. Mould manufacturing, 2008. 8（2）：73-75.
