The Research of Three-Phase Power System Data Detecting Device Based on ADUC836

Abstract:

In the distributed power system, many data in every node needs to be monitored, but the function of current electrical measuring instruments is limited, which make it difficult for organizing a full function node. This paper proposes a kind of analyzer for measuring key data of three-phase power system, and this analyzer is designed on MCU-ADUC836 with mini transformer. Functions of data monitoring, record and online analyzing are realized by it, and the result shows that the embedded three-phase power system data analyzer obtains characters of high accuracy and reduces the number of measuring instruments in the distributed power system.

• Periodical: Advanced Materials Research (Volume 1055)
• Pages: 114-117
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1055.114
• Online since: November 2014
• Authors: Pei Huang
• Keywords: ADUC836, Data Detecting, Distributed Power System

References

[1] McHann, S.E. Grid analytics: How much data do you really need. Rural Electric Power Conference (REPC), 2013 IEEE. pp: C3-1-C3-4.

DOI: 10.1109/repcon.2013.6681858

[2] Hamamatsu, K. A new approach to the implementation of intranet-based measurement and monitoring. Developments in Power System Protection, 2001, Seventh International Conference on (IEE). pp: 102-105.

DOI: 10.1049/cp:20010110

[3] Pathak, J. ; Iowa State University ; Yong Jiang ; Honavar, V. ; McCalley, James. Condition Data Aggregation with Application to Failure Rate Calculation of Power Transformers. System Sciences, 2006. HICSS '06. Proceedings of the 39th Annual Hawaii International Conference. Vol(10). p: 241a.

DOI: 10.1109/hicss.2006.93

[4] Analog Devices: ADUC836-datasheet, (2008).

[5] S.X. Qian. Research on the characteristic gas acquisition and data processing system for power transformer. Advanced Intelligent Mechatronics, 2008. AIM 2008. IEEE/ASME International Conference. pp: 728 - 733.

DOI: 10.1109/aim.2008.4601750
