Experimental Study on Orbital Drilling Force and Machining Quality of CFRP

Abstract:

This paper aims to investigate orbital drilling process in carbon-fiber reinforced plastic (CFRP) composites with multi-point orbital drilling tool based on the robot automatic drilling system. One orthogonal experiment has been carried out, and the cutting forces of different parameters were measured online by dynamometer. Furthermore, the cutting force model was established through regression analysis, and the impacts of cutting parameters on thrust force were deeply analyzed. In addition, delamination and tear defects were inspected respectively, and the relationship between thrust force and delamination and tear was discussed. Our results indicate that thrust force increased with the increasing feed rate and axial feed depth, while decreased with the increasing spindle speed. Axial feed depth was found as the predominant factor on thrust force and defects. At last, the cutting parameters was optimized and then thrust force decreased more than 26% with almost none tear and burr around the hole, which indicates a better machine quality.

• Periodical: Advanced Materials Research (Volumes 1061-1062)
• Pages: 542-549
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1061-1062.542
• Online since: December 2014
• Authors: Xue Mei Chen, Qing Liang Chen*, Feng Tao He, Xi Feng Fan
• Keywords: CFRP, Cutting Force, Delamination, Orbital Drilling, Orthogonal Experiment, Tear

References

[1] Duan YS, Zhou XQ, Hou JS (2012) Status of manufacturing technology in large aircraft composites wing. Aeronaut Manuf Technol (in Chinese) 18: 34-37.

[2] Qin XD, Chen SM, Liu WC (2009) Development and application of hole helical milling technology in aviation manufacturing assembly industry. Aeronaut Manuf Technol (in Chinese) 6: 58-60.

[3] E Whinnem (2006) Development and Deployment of Orbital Drilling at Boeing. Aerospace Manufacturing and Automated Fastening Conference and Exhibition. 01: 3152-3156.

[4] E Whinnem (2008) Development of Orbital Drilling for the Boeing 787. SAE Int J Aerosp. 01: 231 7-2322.

DOI: 10.4271/2008-01-2317

[5] NI WY (2007) Orbital Drilling of Aerospace Materials. Aerospace Manufacturing and Automated Fastening Conference and Exhibition 01: 3814-3822.

[6] Denkena B, Boehnke D, Dege JH (2008) Helical milling of CERP-titanium compounds. CIRP J Manuf Sci Technol 1: 64-69.

DOI: 10.1016/j.cirpj.2008.09.009

[7] Brinksmeier E, Fangmann S, Meyer I (2008) Orbital drilling kinematics. Prod Eng Devel 2: 277- 283.

DOI: 10.1007/s11740-008-0111-7

[8] Luís Miguel P Durão, Daniel JS Gonçalves, João Manuel RS Tavares et al (2011) Comparative analysis of drills for composite laminates. J Compos Mater 46: 1649-1659.

DOI: 10.1177/0021998311421690

[9] Gaitonde VN, Karnik SR, Campos RJ (2011) A study aimed at minimizing delamination during drilling of CFRP composites. J Compos Mater 45(22): 2359-2368.

DOI: 10.1177/0021998311401087

[10] Wang B, Gao H, Bi MZ (2012) Mechanism of Reduction of Damage during Orbital Drilling of C/E Composites. J Mech Eng (in Chinese) 15(48): 173-181.

[11] Wang HY, Qin XD, Ren CZ, Wang Q (2012) Prediction of cutting forces in helical milling process. Int J Adv Manuf Technol 58: 849-859.

DOI: 10.1007/s00170-011-3435-y

[12] Li ZQ, Liu Q Peng C, Sun X (2011) Cutting force modeling and simulation for hole-making operation by helical milling. Proc SPIE 7997: 799703. doi: 10. 1117/12. 883034.

[13] Liu CY, Wang G, Matthew S. Dargusch (2012) Modelling, simulation and experimental investigation of cutting forces during helical milling operations. Int J Adv Manuf Technol. doi 10. 1007/s00170-012-3951-4.

DOI: 10.1007/s00170-012-3951-4

[14] Wang HY, Qin XD, Li H, Ren CZ (2013) Analysis of cutting forces in helical milling of carbon fiber-reinforced plastics. J Eng Manuf 227: 62-74.

[15] Herbert Schulz, He N (2010) The High Speed Machining Fundamentals and Application. Beijing: Science Press.

[16] Chen K (2006) Experiment Design and Analysis. Tsinghua University Press, Beijing. Zhang HJ, Chen WY, Chen DC (2004) Investigation of the exit defects in drilling carbon fibre-reinforced plastic plates. J Mech Eng (in Chinese) 7(40): 150-155.

DOI: 10.3901/jme.2004.07.150
