Effect of Pre-Heating Temperature on Microstructure and Properties of 22MnB5 Steel Hot Stamping

Abstract:

The hot stamping process of ultra high strength steel(UHSS) sheet is an innovative way to manufacture the components with a ultra high tensile strength. The sufficiency of martensitic transformation in formed component is affected by pre-heating temperature of blank directly. In this paper, experiments of heating UHSS blanks to 700°C, 800°C, 900°C and 1000°C were implemented to investigate the effect of pre-heating temperature on the formed component’s microstructure and mechanical properties. The results indicate that 900°C is the best pre-heating temperature for hot stamping process. The microstructure of formed component is all fine and uniform martensite. Meanwhile, tensile strength and vickers hardness raise up to 1580MPa and 450HV, respectively.

• Periodical: Advanced Materials Research (Volume 1063)
• Pages: 108-111
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1063.108
• Online since: December 2014
• Authors: Ping Li, Yu Sheng Liu, Tian Zong Gongzi, Ke Min Xue*
• Keywords: 22MnB5, Hot Stamping, Microstructure, Pre-Heating Temperature

References

[1] Turetta A, Bruschi S and Ghiotti A, Investigation of 22MnB5 formability in hot stamping operations, Journal of Materials Processing Technology. 177 (2006) 396-400.

DOI: 10.1016/j.jmatprotec.2006.04.041

[2] Liu W, Liu H and Xing Z, Effect of tool temperature and punch speed on hot stamping of ultra high strength steel, Transactions of Nonferrous Metals Society of China. 22 (2012) 534-541.

DOI: 10.1016/s1003-6326(12)61757-9

[3] Liu H, Jin X and Dong H, Martensitic microstructural transformations from the hot stamping, quenching and partitioning process, Materials characterization. 62 (2011) 223-227.

DOI: 10.1016/j.matchar.2010.12.003

[4] Tekkaya A E, Karbasian H and Homberg W, Thermo-mechanical coupled simulation of hot stamping components for process design, Production Engineering. 1 (2007) 85-89.

DOI: 10.1007/s11740-007-0025-9

[5] George R, Bardelcik A and Worswick M J, Hot forming of boron steels using heated and cooled tooling for tailored properties, Journal of Materials Processing Technology. 212 (2012) 2386-2399.

DOI: 10.1016/j.jmatprotec.2012.06.028

[6] Bok H H, Lee M G and Pavlina E J, Comparative study of the prediction of microstructure and mechanical properties for a hot-stamped B-pillar reinforcing part, International Journal of Mechanical Sciences. 53 (2011) 744-752.

DOI: 10.1016/j.ijmecsci.2011.06.006

[7] Karbasian H and Tekkaya A E, A review on hot stamping, Journal of Materials Processing Technology. 210 (2010) 2103-2118.

DOI: 10.1016/j.jmatprotec.2010.07.019

[8] Somani M C, Karjalainen L P and Eriksson M, Dimensional changes and microstructural evolution in a B-bearing steel in the simulated forming and quenching process, ISIJ international. 41 (2001) 361-367.

DOI: 10.2355/isijinternational.41.361
