Application and Study on Tailing Dam Saturation-Line Detection of Based on Ground Penetrating Radar Technology

Abstract:

Just because that saturation-line is a primary factor to affect both security and stability of tailing dam, it is of great significance to define its location and distribution. Different sand body moisture contents of the saturation-line up-down layer lead to distinctive dielectric properties, which is essential to geophysical prospecting. On the basis of feasibility study of using radar to detect the saturation-line, the approach is applied practically in one dam. It is predicted that Ground Penetrating Radar (GPR) not only has a series of advantages such as intuitional image, shorter work period, greater detective depth, less interference to dams; but also can acquire calculable depth and location data, which can forecast holistic distribution of the saturation-line from a macroscopic view, and of which diagrams and results can offer reliable basis on safety, early warning analysis and security management.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 109-113
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.109
• Online since: December 2014
• Authors: Wei Liu*, Ren Cheng Xiao, Zhong You Wang
• Keywords: Ground Penetrating Radar, Saturation Line, Tailing Dam

References

[1] ChunheYang, Chao Zhang . Safety assessment and Disease Management on Tailing Dams. Wuhan: Hubei People's Publishing House, 2005. (In Chinese).

[2] Guangzhi Yin, Zuoan Wei, JiangXu. Stability Analysis on Dams and Fine Grained Tailings. Chongqing University Press, 2004. (In Chinese).

[3] State Administration of Work Safety. AQ 2006 — 2005 Safety technical regulations for the tailing pond. Beijing：China Coal Industry Publishing House，2006. (In Chinese).

[4] Zhaofa Zeng, Sixin Liu, Xuan Feng. Ground Penetrating Radar Principle and Application. Beijing: Electronic Industry Press, 2010. (In Chinese).

[5] Chuanxiao Liu. Research on the mechanism of probing cavity with Ground Penetrating Radar and analysis on application examples. China Journal of Rock Mechanics and Egineering. 2000, Vol. 19(2): 238-241. (In Chinese).

[6] Dunyi Deng, Shuqiang Shao, Jianping Pan. Numerical simulation for the slope stability of tailing dam under natural condition. Chinese Journal of Underground Space and Engineering, 2010, 6(2): 414–428. (In Chinese).

[7] Seje CarlstenSam, Johanson and Anders Worman. Radar Techniques for Indicating Internal Erosion in Embankment Dams. Journal of Applied Geophysics, 1995, Vol. 33(1-3): 143-146.

DOI: 10.1016/0926-9851(95)90037-3

[8] W.L. Lai *, W. F. Tsang. Characterization of pore systems of air/water-cured concrete using ground penetrating radar (GPR) through continuous water injection. Construction and Building Materials, 2008, Vol. 22: 250-256.

DOI: 10.1016/j.conbuildmat.2006.08.021

[9] SALGUEIRO A. R., PEREIRA H G, RICO M .T., et al. Application of correspondence analysis in the assessment of min e tailings dam breakage risk in the Mediterranean region [J]. Risk Analysis, 2008, 28(1): 13-23.

DOI: 10.1111/j.1539-6924.2008.00998.x

[10] MAINALI G. Monitoring of tailings dams with geophysical methods[Ph. D. Thesis][D]. Sweden: Luleå University of Technology, (2006).

[11] Song Zhou. Detection on dam saturation-line by Ground Penetrating Radar. Water Resources and Hydropower Engineering, 2001, Vol. 32(10): 38-39. (In Chinese).

[12] Yongqiang Wang, Qinwen Tan, Yihu Zhang. Tailings dam saturation-line detection of radar technology. China Mining Industry, 2008, Vol. 21(8): 116-119.

[13] Xingxin Xu, Jin Wu, Xiangan Wu. Detection on saturation-line of Radar application. Water Resources and Hydropower Engineering, 1998, Vol. 29(4): 42-44. (In Chinese).

[14] Wei He, Kui Zhao, Hognxing Liu. Saturation-line Detected by ground penetrating radar application on stability analysis. Non-ferrous Metal Engineering. 2014, Vol. 15: 68-70. (In Chinese).
