Top and Bottom Ring Beam Strengthening Research on Gravity Abutment of Plain Concrete

Abstract:

It is major, simple structure and wide scope of use on Gravity abutment of plain concrete, But most of the wall of abutment appears irregular cracks, affect the economy and durability of the abutment and bridge seriously. The paper is based on a bridge of Jiang Xi Rui Xun high-speed engineering, analysis the crack mechanism of abutment by using large-scale finite element software ANSYS to establish reinforcement simulation model of top and bottom ring beam. The stress and vertical deflection of the abutment are meet the requirements, it is meaningful for gravity abutment of plain concrete Strengthening in the future.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 1300-1304
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.1300
• Online since: December 2014
• Authors: Fei Guo*, Hui Fang Zhu, Fang Cheng Huang
• Keywords: ANSYS, Crack, Gravity Abutment of Plain Concrete, Strengthening, Top and Bottom Ring Beam

References

[1] Liu Linjia. Bridge Engineering[M]. China Communications Press, Beijing, (2006).

[2] CCCC First Highway Engineering Co, Ltd. JTJ TF5042011 Technical specification for construction of highway bridge and culverts[S]. China Communications Press, Beijing, (2001).

[3] Shanxi Provincial Highway Bureau, Chang'an University. JTJ H1142004 Code for maintenance of highway bridge and culverts[S]. China Communications Press, Beijing, (2001).

[4] CCCC First Highway Consultants Co. , Ltd. JTJ/T J2342008 Technical Specifications for Strengthening Construction of HighwayBridges[S]. China Communications Press, Beijing, (2008).

[5] Yang Fubin An analysis of the repair of cone-shaped platform and strengthening of piers in real engineering[J]. Fujian Architecture&Construction, 2007(12): 89.
