Numerical Simulation of Axial-Flow Fan with Adjustable Vanes in the Pant

Abstract:

Based on the axial-flow fan with adjustable vanes in a power plant of Tangshan, the internal flow with different inlet speeds during the axial-flow fan run were simulated with FLUENT software package. The results showed that if inlet velocity was greater than the critical velocity, the flow was relatively uniform. If inlet velocity was lower than the critical velocity, a vortex caused by tip leakage would decrease fan efficiency and induce surge.The impact increased gradually with increasing of the moving blade angle. The results were consistent with the actual and provided further evidence for high efficient and safe operation of axial-flow fans.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 2141-2146
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.2141
• Online since: December 2014
• Authors: Yuan Yuan Li*, Zhen Ning Zhao, Zhi Qiang Wen
• Keywords: Axial-Flow Fan, Fluent Software, Inlet Speed, Vortices

References

[1] W. Fujun: CFD analysis (Tsinghua University press, Beijing, 2004 ).

[2] H. Zhanzhong: Examples and analysis of FLUENT simulation (Beijing Institute of Technology press, Beijing, 2009).

[3] John D. Anderson, Jr: Computational fluid dunamics—The basics with applications(Tsinghua University press, Beijing, 2002 ).
