Experimental Research on the Prestress and Static Behavior of a Cable-Strut Tensile Structure Model

Abstract:

A cable-strut tensile structure model with the diameter of 5.0m was designed and made to study the prestress and static behavior on the base of theory analysis. New schemes of the boundary compression ring, the cables and struts with the adjustable length, the connection nodes were designed and the least square method to fit the element force and strain curve was proposed. The initial prestress distribution and the responses of the model under full-span node load, half-span node load and 1/4-span node load were investigated. The experimental results indicate the cable-strut tensile structure will achieve the designed initial prestress while every element was tensioned to designed length. The outer planar stiffness of the structure is poor and easy to lost stability when subjected to asymmetric loads. The measured values and computed ones are almost consistent, which indicates the validity of the model design and the accuracy of the proposed methods.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 938-942
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.938
• Online since: December 2014
• Authors: Lin Fu, Lian Meng Chen*, Bin Wu, Zi Hao Zhang, Xi Guo Ye, Yi Yi Zhou
• Keywords: Cable-Strut Tensile Structure, Initial Prestress, Model Design, Model Experiment, Static Behavior

References

[1] S. Pellegrino．Strucutural computation with the singular value decomposition of equilibrium matrix. International Journal of Solids and Structures， 30(21)：3025-3035(1993).

DOI: 10.1016/0020-7683(93)90210-x

[2] S. Pellegrino, C.R. Calladine. Matrix analysis of statically and kinematically indeterminate frameworks. International Journal of Solids Structures, 22(4): 409-428(1986).

DOI: 10.1016/0020-7683(86)90014-4

[3] S.L. Dong, X.F. Yuan. A quick calculation method for initial prestress distribution of Geiger domes. Spatial Structure, 9(2), 3-8(2003).

[4] S.L. Dong, X.F. Yuan. A simplified calculation method for initial prestress distribution of Levy cable domes. Journal of Building Structures, 25(6), 9-14 (2004).

[5] X.F. Yuan, L.M. Chen, S.L. Dong. Prestress design of cable domes with new forms. International Journal of Solids and Structures. 44（9）：2773-2782(2007).

DOI: 10.1016/j.ijsolstr.2006.08.026

[6] L.M. Chen, S.L. Dong．Optimal prestress design and construction technique of cable-strut tension structures with multi-overall selfstress modes. Advances in Structural Engineering. 16（10）：1633-1644 (2013).

DOI: 10.1260/1369-4332.16.10.1633

[7] X.F. Yuan, S.L. Dong. Nonlinear analysis and optimum design of cable domes. Engineering Structures, 34(7): 586-592 (2002).

[8] X.F. Yuan, S.L. Dong. Study on static behaviour of cable domes. International Association of Shell and Space Structures, 43(2): 81-91(2002).
