Calculation and Optimization of Cable Connector Electric Field Intensity in High Speed Rail Based on Finite Element

Abstract:

When high speed rail run at high altitudes, over-voltage occurred in the process of operating makes the air gap of cable connector breakdown. It is necessary to clear the electric field intensity distribution and its numerical size of cable connector to make an optimization in order to curb this phenomenon. For this reason, 1:1 finite element model is established by the use of ANSYS software, and the simulation results show that the maximum value of the electric field intensity of cable connector can reach 644.05 kV/m. The maximum electric field is reduced with adding an insulating jacket to the head of cable connector. When the thickness of the insulating jacket is respectively 3 mm, 5 mm, 7 mm, 10 mm, the maximum electric field intensity percentage decreased is 10.26%, 11.4%, 16.1%, and 16.7%. So the insulating jacket would be an effective measure to inhibiting the breakdown of the air gap at the cable connector.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 1175-1178
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.1175
• Online since: December 2014
• Authors: Bu Chao Jia, Hong Yu Liu, Qing Bo Mu, Jian Qiao Ma
• Keywords: Cable Connector, Electric Field Intensity, High Altitude, High Speed Rail

References

[1] Duan Man-zhen, Dong Bo, Li Zheng, Cao Hui-yun. Resistance and the Inevitable Trend of China High-speed Rail Development[J]. Modern Urban Research, 2012, 10, 94-98.

[2] Rethinkin the current development of high-speed rail economy[J]. Journal of Hubei University of Economics (Humanities and Social Sciences), 2011, 11, VOL. 8 NO. 11, 21-26.

[3] Campos, J, D. R. Ginés & B. Ignacio (2009), Some stylized facts about high-speed rail: A review "Some stylized facts about high-speed rail: A review of HSR experiences around the world, Transport Policy, 16: 19-28.

DOI: 10.1016/j.tranpol.2009.02.008

[5] Givoni, M. （2006）, Development and impact of the modern high-speed train: A review, Transport Reviews, 5: 593-611.

DOI: 10.1080/01441640600589319

[6] Dai Rongli. Ethics Review of China high speed rail development[J]. Journal of University of Science and Technology Beijing, 2012, 8, Vol. 28, No. 2, 51-59.

[7] Chinese railway operation chart usher in a new high-speed rail adjustment strung", Regional EconomicCircle"[EB/OL]. http: /news. ifeng. com/a/20140709/41077789_0. shtml, 2014, 07, 09.

[8] Chinese high speed rail models List [EB/OL]. http: /news. sohu. com/s2012/gaotiechexing.

[9] Arduin, Jean-pievre & Jincheng. Ni, French TGV network development, Japan Railway & Transport Review, 40: 22-28.

[10] Nakagawa,D. & M. Hatoko, Reevaluation of Japanese high-speed rail construction: Recent situation of the north corridor Shinkansen and its way to completion, Transport Policy, 14: 150-164.

DOI: 10.1016/j.tranpol.2006.11.004
