The Research of the Distributed Grid Model Maintenance Technologies Based on Logical Unify

Abstract:

To solve the model consistency problem between the power systems which use model combination, and to meet the needs of different models proposed for the grid, in this paper is based on the research of whole grid model information and application requirements, and proposed the method of the model maintenance based on logical unify. And this paper describes the "two deployment, unified management, partition maintenance, on-demand services" architecture design, and detailed model business processes and key technical details. Finally, through prototype software verification of the research, we prove that these model maintenance and management technologies can achieve the whole grid model to efficiently store and manage, and can adapt to various model requirements.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 1430-1436
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.1430
• Online since: December 2014
• Authors: Hong Zhang*, Wei Jin Zhuang, Shu Hai Feng
• Keywords: Logical Unify, On-Demand Service, Partition Maintenance, Unified Management, Wide Distribution

References

[1] Xiao Shijie, Consideration of technology for construction Chinese smart grid[J]. Automation of Electric Power Systems, 2009, 33(9): 1~4.

[2] JIANG Daozhuo, SHEN TuGang, LI Haixiang et al. Significance and Roles of Standardized Basic Information in Developing Smart Grid[J]. Automation of Electric Power Systems, 2009, 33(20): 1-5.

[3] QIAN Jing, GE Minhui, MI Weimin et al. Management of East China Power Grid Hierarchy Model Based on IEC61970[J]. Power System Technology, 2007, 31: 295-298.

[4] XIN Yaozhong, MI Weimin, JIANG Guodong, XU Dandan, YE Fei and DU Peng. Scheme of Application Model Information Sharing Between Control Centers Based on CIM/E[J]. Automation of Electric Power Systems, 2013, 37(8): 1-5.

[5] IEC 61970-453-2008. Energy management system application program interface (EMS-API)-Part 453: CIM based graphics exchange, (2008).

DOI: 10.3403/30151503

[6] IEC 61970-452, EMS API-Part 452: CIM Model Exchange Specification.

[7] http: /hadoop. apache. org/common/docs/current/hdfs_design. html.

[8] http: /hadoop. apache. org/hbase.

[9] CAO Yang, YAO Jianguo, YANG Shengchun, JIANG Hai, GAO Zhiyuan. Latest Advancements of Smart Grid Core Standard IEC 61970[J]. Automation of Electric Power Systems, 2011, 35(17): 1~4.

[10] CHEN Ailin, GENG Mingzhi, ZHANG Haidong, SONG Xin. Key Technologies of Model Sharing Between Smart Substation and Control Centre[J]. Automation of Electric Power Systems, 2012, 36(9): 72~76.

DOI: 10.1109/powercon.2014.6993491
