Application of Modbus Protocol in the Automatic Safety Device

Abstract:

The traditional HMI ( human-machine interface ) of automatic safety device is lack of beauty and friendship. With the development of smart grid, there are more and more high requirements of the HMI. The automatic safety device was divided into the HMI module and the device main body. An industrial touch screen which supports for Modbus protocol, was selected as the HMI module of the automatic safety device. The HMI data was extracted into the standard data of Modbus protocol, and mapped to the unified address space of Modbus protocol. Modbus RTU mode was used to achieve the data communication between the HMI module and the device main body. This method not only makes the display content richer, interface more user-friendly, but also makes the product development cycle shorter and the product more scalable.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 765-769
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.765
• Online since: December 2014
• Authors: Qing Hua Si*, Hai Bo Xu, Jun Xu, Gao Yang Xu, Zhen Feng Ye
• Keywords: Automatic Safety Device, HMI, Modbus Protocol

References

[1] Guide on Security and Stability DL 755-2001 for Power System, China Electric Power Press, (2001), in Chinese.

[2] Yizhe Fu: Servo Control Vol. 1 (2013), pp.61-65, in Chinese.

[3] Shengxin Zhang, Xugui Zhou, Yanjie Li: PLC&FA. Vol. 2 (2014), pp.90-93, in Chinese.

[4] Hongyue Pan: Measurement Technique Vol. 4 (2002), pp.35-36, in Chinese.

[5] Heheng Yan, Xiaohua Wang, Weiming Tong: Techniques of Automation and Application Vol. 25 (2006), pp.49-51, in Chinese.

[6] Hua Meng, Pengda Wang, Mingwei Li: Instrument Technique and Sensor Vol. 10 (2009), pp.58-60, in Chinese.

[7] Technical specification for Security & Stability Control Equipment Q/GDW421-2010, China Electric Power Press, (2010), in Chinese.

[8] Modicon Modbus ProtocoI Reference Guide . MODICON, Inc . , Industrial Automation Systems, (1996).
