Improved Retrieval of Reflectivity Factor for Airborne Weather Radar

Abstract:

For the airborne weather radar signal processing, the intensity of the meteorological targets is represented by the physical quantity called reflectivity factor. When observing the middle-or long-range meteorological targets at low altitude from a high-altitude radar platform, due to the incomplete beam filling, the retrieval result of the reflectivity factor is much less than the actual value. In this paper, we firstly introduce a beam filling coefficient into the weather radar equation and then present its estimation method based on the real-time radar operating parameters. The validity of the proposed method is then verified by processing the raw-data of the simulated meteorological targets.

• Periodical: Advanced Materials Research (Volumes 1073-1076)
• Pages: 611-614
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1073-1076.611
• Online since: December 2014
• Authors: Tian Shun Xiang, Yong Li*, Di Wu, Li He
• Keywords: Airborne Weather Radar, Beam Filling Coefficient, Parameter Estimation, Reflectivity Factor

References

[1] Mingbao Hu, The Weather Radar Detection and Application, Meteorological Press, Beijing, (2007).

[2] Xinming Pan, Yi Xiong, Reflectivity factor and factor analysis of the error of the solution, 2nd conference of radar meteorology and the weather radar committee of China, Hefei, (2006).

[3] VignaI B., G. Galli, J. Joss, et a1, Three methods to determine profiles of reflectivity from volumetric radar data to correct precipitation estimates, Appl. Meteor. 39 (2000) 1715-1726.

DOI: 10.1175/1520-0450-39.10.1715

[4] Jingsi Wang, Radar range equation for meteorological targets, 1996 CIE International Conference, BeiJing, (1996).

DOI: 10.1109/icr.1996.574534

[5] You He, Jianjuan Xiu, Jingwei Zhang, et al, Radar Data Processing and Application, Housing of Electronics Industry, Beijing, (2009).

[6] Tim Stewart，James DeArmon，David Chaloux, Using flight information to improve weather avoidance predictions, 2013 Aviation Technology, Integration, and Operations Conference, Los Angeles, (2013).

DOI: 10.2514/6.2013-4377

[7] Yi Fan, RenBiao Wu, ZhiChao Meng，et a1, Wind shear signal simulation of the airborne weather radar , 201l IEEE Radar Conference, Kansas City, (2011).

DOI: 10.1109/radar.2011.5960630

[8] Renbiao Wu, Pengju Hu, Xiaoguang Lu, Simulation of airborne weather radar signals, Journal of Civil Aviation University of China. 30 (2011) 351-355.

[9] Huajun Duan, Study on signal simulation of airborne weather radar and the methods for ground clutter suppression, Nanjing University of Aeronautics & Astronautics, Nanjing, China (2011).
