Occurrence and Control of Crack on Counterweight of Forklift Cast with High Manganese Pig Iron

Abstract:

Cracks easily generate in counterweight of forklift cast with high manganese pig iron which is by-product of smelters or low-grade manganese pig iron of Guangxi province of China. The causes of cracks formation and the solutions of cracks elimination are discussed. A large amount of carbides, phosphorus eutectic, inclusions, and arsenic element distribute on grain boundary of counterweight that causes crack. The measures to solve the cracks are as following: casting process would be improved, carbides and inclusions would be refined by adding rare earth, and arsenic would be eliminated by adding dearsenic catalyst which is composed of Ca-Fe alloy and the strong reducibility based additives. The distribution of phosphorus would be improved and phosphorus eutectic would be eliminated by adding 0.08%~0.15 %( wt %) Al or 1%~2 %( wt %) Mo.

• Periodical: Advanced Materials Research (Volume 1078)
• Pages: 12-19
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1078.12
• Online since: December 2014
• Authors: An Min Li, Qi Feng Zheng, Zheng Yong Yu, Ruo Huai Chen, Yu Wei Huang
• Keywords: Counterweight, Crack, High Manganese Pig Iron, Microstructure

References

[1] N. Fan and F.M. Tian: China Mining Magazine Vol. 6 (2009), p.91.

[2] Z.Z. Tan: Nanning: National Manganese Mine Enterprises (Manager) Association (2009), p.50.

[3] S. Kun Hong: China's Manganese Industry Vol. 29(2011), p.13.

[4] F.L. Xue: Foundry Technology Vol. 01(2006), p.95.

[5] KUYUCAK S, NEWCOMBE P: AFS Trans. Vol. 111(2003), p.1127.

[6] KUYUCAK S, ZAVADIL R: AFS Trans. Vol. 110(2002), p.1281.

[7] RODIONOV D M, LYUBIMOV M G, MISHUTIN Y A: Phys. Met. Metall. Vol. 68 (1989), p.73.

[8] P.X. Fu,W.N. Zhang X.H. Kang: Casting Vol. 04(2007), p.409.

[9] Y.L. Lei: Modern Metallurgy Vol. 4(1996), p.82.

[10] M.Y. Li, H.B. Li, L.P. Xia and H.H. Zhao: Metallurgical Standardization & Quality Vol. 02(2004), p.11.

[11] H.Z. Zhuang: Metallurgical Collections Vol. 06(1996), p.7.

[12] J.Q. Zhang, W.B. Zhang and H.Q. Wang: Foundry Technology Vol. 04(2006), p.310.

[13] M.Y. Zhu, in: Modern Metallurgy (pig iron metallurgy volume), edtied by M.Y. Zhu, Metallurgical Industry Press, Beijing(2005), in press.

[14] L.G. Luo, J.J. Wang, H. Kong and L. Zhou: The Chinese Journal of Process Engineering Vol. 04(2011), p.595.
