Research of Directional Stress Distribution on the Fully Plastic Bulged Pressure Hull

Abstract:

In order to improve the ultimate capacity of pressure hull, a new method to improve the external bearing limit is put forward and residual stress is used. Based on the lame formula, the bilinear hardening model is considered to deduce the residual stress formula. Two influence parameters are analyzed by theoretical and numerical methods. The accordance of results shows that the accuracy of theoretical derivation can be verified by FEM. The 3D models with residual stress or not are built in ABAQUS. According to a lot of data of simulation experiments, the result indicates that the directional residual stress is useful, especially compressive on the outer surface of the pipe and the hoop stress keeps tensile on the inside surface. This kind of stress distribution is helpful to the cylinder structure and can improve its ultimate capacity of external pressure. Thus, the formula considering hardening material can guide the full plastic bulging to produce the desired stress distribution.

• Periodical: Advanced Materials Research (Volume 1082)
• Pages: 412-415
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1082.412
• Online since: December 2014
• Authors: Guo Chun Lu, Guan Nan Chu*
• Keywords: Directional Stress, Fully Plastic Bulging, Hardening Material, Pressure Hull, Ultimate Capacity

References

[1] Dahlman Patrik, Gunnberg Fredrik, Jacobson Michael. The influence of rake angle, cutting feed and cutting depth on residual stresses in hard turning[J]. Journal of Materials Processing Technology, 2004, 147(2): 181-184.

DOI: 10.1016/j.jmatprotec.2003.12.014

[2] Sadat A B, Bailey J A. Residual stresses in turned AISI4340 steel[J]. Experimental Mechanics, 1987, 27(1): 80-85.

DOI: 10.1007/bf02318868

[3] R. B. Tait, J. Press. An experimental study of the residual stresses and their alleviation in tube to tube sheet welds of industrial boilers[J]. Engineering Failure Analysis, 2001, 8(1): 15- 27.

DOI: 10.1016/s1350-6307(00)00008-x

[4] Huang X P, Cui W C. Effect of Bauschinger Effect and Yield Criterion on Residual Stress Distribution of Autofrettaged Tube[J]. Journal of Pressure Vessel Technology, 2006, 128(2): 212-216.

DOI: 10.1115/1.2172621

[5] Bingye Xu, Xinsheng Liu. Application of elastic-plastic mechanics. Pressure Tsinghua University. , pp.191-206, in Chines.
