A Silicon Semiconductor Temperature Sensor Applied for RFID Tag

Abstract:

A new type of silicon semiconductor temperature sensor applied for RFID tag chip is designed based on the linear temperature characteristic of base-emitter voltage of parasitic substrate PNP transistor. A novel switched capacitor integrator based on positive-negative synchronous integration is introduced to amplify the weak temperature signal precisely and provide a method to represent the temperature in analog domain. Temperature quantization is accomplished by a 12-bit ultra-low-power successive approximation analog-to-digital converter providing a resolution of 0.03125°C/LSB. The circuit was simulated by using device model of 0.18-μm CMOS process. The output integration swing is 2VPP and the average current dissipation is 38.91μA at 1.8V supply. The sensor achieves an accuracy of -0.1°C to +0.33°C in the temperature range of -39°C to 89°C.

• Periodical: Advanced Materials Research (Volume 1082)
• Pages: 541-546
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1082.541
• Online since: December 2014
• Authors: Hui Chen*, Wei Ping Jing, Shao Qing Huang
• Keywords: ADC, Parasitic Substrate PNP Transistor, RFID, Silicon Semiconductor Temperature Sensor, Switched-Capacitor Integrator

References

[1] C. H. Xu, P. J. Gao, W. Y. Che, et al., An ultra-low-power CMOS temperature sensor for RFID applications, J. Semiconductors 30(4) (2009) 045003.

[2] K. Opasjumruskit, T. Thanthipwan, O. Sathusen, et al., Self-powered wireless temperature sensors exploit RFID technology, IEEE Pervasive Comput. 5(1) (2006) 54-56.

DOI: 10.1109/mprv.2006.15

[3] H. W. Shen, L. L. Li and Y. M. Zhou, Fully integrated passive UHF RFID tag with temperature sensor for environment monitoring, in Proc. ASICON (2007) 360-363.

DOI: 10.1109/icasic.2007.4415641

[4] M. K. Law, A. Bermak and H. C. Luong, A sub-μW embedded CMOS temperature sensor for RFID food monitoring application, IEEE J. Solid-State Circuits 45(6) (2010) 1246-1255.

DOI: 10.1109/jssc.2010.2047456

[5] A. J. M. Boomkamp and G. C. M. Meijer, An accurate biomedical temperature transducer with on-chip microcomputer interfacing, in Proc. ESSCIRC (1985) 420-423.

DOI: 10.1109/esscirc.1985.5468191

[6] M. A. P. Pertijs and J. H. Huijsing, Precision Temperature Sensor in CMOS Technology, Springer, Dordrecht, (2006).

[7] G. C. M. Meijer, G. Wang and F. Fruett, Temperature sensors and voltage references implemented in CMOS technology, IEEE Sensors J. 1(3) (2001) 225-234.

DOI: 10.1109/jsen.2001.954835

[8] C. C. Enz and G. C. Temes, Circuit techniques for reducing the effects of op-amp imperfections: auto-zeroing, correlated double sampling, and chopper stabilization, Proc. IEEE 84(11) (1996) 1584-1614.

DOI: 10.1109/5.542410

[9] B. Razavi, Design of Analog CMOS Integrated Circuits, McGraw-Hill, New York, (2000).
