Investigation of Surface Phase Layers on GaAs after Selective Chemical Etching

Abstract:

Normal 0 false false false RU X-NONE X-NONE The combination of methods of voltammetry, Raman spectroscopy, and X-ray reflectometry for the first time has been applied for the more comprehensive investigation of interfacial boundaries of GaAs, i.e. determination of phase distribution and thickness of the phase layers. The conditions for the formation of elemental arsenic on a GaAs surface in the process of selective dissolution are discussed. The stability of interfacial boundaries in air has also been studied. The investigations have shown that air storage lead to the oxidation of formed As⁰ and reorganization of GaAs interfacial boundary accompanied by the formation of Ga₂O₃ and As⁰ as a result of a reaction between As₂O₃ and GaAs. The results on interfacial boundaries composition were found to be correlated with the theoretical data. /* Style Definitions */ table.MsoNormalTable {mso-style-name:"Обычная таблица"; mso-tstyle-rowband-size:0; mso-tstyle-colband-size:0; mso-style-noshow:yes; mso-style-priority:99; mso-style-parent:""; mso-padding-alt:0cm 5.4pt 0cm 5.4pt; mso-para-margin-top:0cm; mso-para-margin-right:0cm; mso-para-margin-bottom:10.0pt; mso-para-margin-left:0cm; line-height:115%; mso-pagination:widow-orphan; font-size:11.0pt; font-family:"Calibri","sans-serif"; mso-ascii-font-family:Calibri; mso-ascii-theme-font:minor-latin; mso-hansi-font-family:Calibri; mso-hansi-theme-font:minor-latin; mso-bidi-font-family:"Times New Roman"; mso-bidi-theme-font:minor-bidi; mso-fareast-language:EN-US;}

You might also be interested in these eBooks

Prospects of Fundamental Sciences Development

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 1085)

Pages:

91-94

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1085.91

Citation:

Cite this paper

Online since:

February 2015

Authors:

Oksana N. Zarubina*, Gennady M. Mokrousov, Alexander G. Touryanski, Igor V. Pirshin, Liubov V. Maliy

Keywords:

Chemical Etching, Gallium Arsenide, Interfacial Transformations, Surface Phase Layer, X-Ray Reflectometry

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] M. Rei Vilar, J. El Beghdadi, F. Debontridder, R. Artzi, R. Naaman, A.M. Ferraria, A.M. Botelho do Rego, Characterization of wet-etched GaAs (100) surfaces, Surf. Interface Anal. 37 (2005) 673-682.

DOI: 10.1002/sia.2062

Google Scholar

[2] J.S. Song, Y.C. Choi, S.H. Seo, D. S Oh., M.W. Cho, T. Yao, M. H Oh, Wet chemical cleaning process of GaAs substrate for ready-to-use, J. Cryst. Growth. 264 (2004) 98-103.

DOI: 10.1016/j.jcrysgro.2003.12.063

Google Scholar

[3] M. Pourbaix, Atlas of electrochemical equilibria in aqueous solution, Pergamon Press, N.Y., (1966).

Google Scholar

[4] O.N. Zarubina, G.M. Mokrousov, E.P. Naiden, The composition and structure of interphase boundaries of III–V semiconductors formed in a liquid medium, Russ. Phys. J. 54, 12 (2012) 1375-1383.

DOI: 10.1007/s11182-012-9757-x

Google Scholar

[5] O.E. Tereshchenko, V.L. Alperovich, A.S. Terekhov, Composition and structure of chemically prepared GaAs(111)A and (111)B surfaces, Surf. Sci. 600 (2006) 577-582.

DOI: 10.1016/j.susc.2005.11.007

Google Scholar

[6] R.M. Feshchenko, I.V. Pirshin, A.G. Touryanski, A.V. Vinogradov, New methods of X-ray reflectometry of solids and thin solid films, J. Russ. Laser Res. 20, 2 (1999) 136-151.

DOI: 10.1007/bf02508690

Google Scholar

[7] T.P. Bekezina, G.M. Mokrousov, Preparation of GaAs surfaces of desired composition, Inorg. Mater+. 36, 9 (2000) 857-863.

DOI: 10.1007/bf02758691

Google Scholar

[8] J. Price, J. Barnett, S. Raghavan, M. Keswani, R. Govindarajan, A study of the interaction of gallium arsenide with wet chemical formulations using thermodynamic calculations and spectroscopic ellipsometry, Microelectron. Eng. 87, 9 (2010).

DOI: 10.1016/j.mee.2009.11.046

Google Scholar

[9] R.R. Campomanes, J.H. Dias da Silva, J. Vilcarromero, L.P. Cardoso, Crystallization of amorphous GaAs films prepared onto different substrates, J. Non-Cryst. Solids. 299-302 (2002) 788-792.

DOI: 10.1016/s0022-3093(01)00983-8

Google Scholar

[10] G. P Schwartz, Analysis of native oxide films and oxide-substrate reactions on III–V semiconductors using thermochemical phase diagrams, Thin Solid Films. 103, 1-3 (1983) 3-16.

DOI: 10.1016/0040-6090(83)90420-0

Google Scholar
