Analysis of a New Processing Method for Small Curvature Aaspheric

Abstract:

For the aspheric processing is complex , time consuming and difficult to guarantte the eccentricity ,this paper introduce a new method of aspheric processing --repairing and polishing methed and describe the principle . Best fit radius, removal function were computed by mathematical model method and the respective performance curves were given by simulation. This methed has the particular advantage of shortening the working time ,reducing the eccentric amount of the element and improving the processing efficiency. Through this processing method, do a series of processing experiments on the smaller aspheric tolerance single crystal silicon aspheric.As the result indicated , plane surface shape error PV 0.52 μm,surface roughness RMS value of single-crystal silicon 0.09 μm ,the center deviation was less than1μm and the surface smoothness meet the standard above the grade Π.

• Periodical: Advanced Materials Research (Volume 1089)
• Pages: 309-314
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1089.309
• Online since: January 2015
• Authors: Xiu Hua Fu*, Yang Liu, Zong He Jia
• Keywords: Aspheric, Aspheric Tolerance, Eccentricity, Finish, Optical Fabrication, Polishing Methed, Repairing Methed, Single-Crystal Silicon

References

[1] Tuell MT, Burge J H, AndersonB. Aspheric Optics: Smoothing the Ripples with Semi - flexible Tools[J]. Optical engineering, 2002, 41(7) : 1473-1474.

DOI: 10.1117/1.1481898

[2] Yang Jiandong, Tian Chunlin high speed grinding technology [M]. Beijing: National Defense Industry Press, 2003. Shangchun.

[3] Min, Zhang Dongmei, Jian-Dong Yang A new study aspherical efficient grinding method [J]. Chinese Mechanical Engineering, (2005).

[4] Shu Rui, Hu Zhonghui, ZHOU Yan-ping A numerical study of new aspheric polishing method [J]. Optical technology . 2005, 31 (3).

[5] He Wang Yan, Cai Li, Park Seung-ho. Analysis of the main difficulties of optical parts processing [J]. Optical technology. 2006 (S1).

[6] Ma Fang, Fu Xiuhua, Jia were together, Xie Ying, Tang Haolong researchers aspheric silicone lens processing technology [J] infrared tracking system. Applied Optics 2012 (04).

[7] If the Po-chi optical surface finish Review [J]. Infrared and Laser . 1991 (4).

[8] Mouguang Yuan, Fu Xiuhua, Sujia Ni, Zhang wise. Small-caliber biaspheric controlled polishing technology research [J]. Journal of Applied Optics. 2009 (05).

[9] Yin Shao Hui, Xu Zhiqiang. Small diameter single crystal silicon composite aspherical ultra-precision machining technology [J]. Chinese photoelectric . (2012).

[10] Lu Yonggui, Yang Jiandong. To investigate the degree of aspheric optics [J]. Changchun University of Technology. 2005 (04).

[11] Xie Ying, Fu Xiuhua, Jia were together, horses, Tanghao Long, field. Research polishing process high order aspheric glass elements microcrystalline [J]. Changchun University of Technology (Natural Science) 2012 (04).

[12] Berge Tatian. Least-squares fitting of aspheric surfaces by a conicoid. Applied Optics . (1989).

DOI: 10.1364/ao.28.004687

[13] Cai Li, Tian Shouxin, Fu Xiuhua eds. Optical parts processing technology [M]. Huazhong Institute of Technology Press, (1987).

[14] Liu Dongmei, Zheng Shuang, Fu Xiuhua, Jia Zong-he. Research on high-precision aspheric processing small-caliber [J]. Changchun University of Technology (Natural Science). 2013(z1).

[15] WANG Quan-dou, LIU Min-cai, ZHANG Hong-xia. Removing function of polishing pad in computer controlled optical polishing[J]. Optical Technique, 2000, 26(1): 32-34. (in Chinese with an English abstract).
