Analysis of Stress Field of Fuel Storage Tank Saddle on LNG-Fuelled Ship

Abstract:

This paper introduces fuel storage tank arrangement and the saddle structure of 296600 tons oil tanker (VLCC). According to the relevant standard, using ANSYS software, finite element modeling of the saddle and nearby hull structure is created. The radial force distribution function of the saddle is deduced under various conditions. The accurate stress state for saddle and nearby is found out by the application of finite element direct calculation method. Through the analysis of the results, the improvement measures are given and the reference for the saddle structure design is provided.

• Periodical: Advanced Materials Research (Volume 1090)
• Pages: 222-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1090.222
• Online since: February 2015
• Authors: Yun Qiu Zhang*, Bo Yang Li, De Dong Hu
• Keywords: Fuel Storage Tank, LNG-Fuelled, Saddle, Stress Field, VLCC

References

[1] WU Heng-tao. Research on operations of LNG tank containers carried by sea, Dalian Maritime University, Dalian, (2013).

[2] Rules for Natural Gas Fuelled Ships[S], China Classification Society, (2013).

[3] LI Chao. Study on the LNG tank design and pressure regulation process of LNG powered ships, Dalian Maritime University, Dalian, (2013).

[4] JIN Quan-zhou, CAO Jiao-long. Fatigue Strength Calculation of Fuel Storage Tank on LNG-fuelled Ship, Ship Engineering suppl. 1, Shanghai, (2013).
