Lifetime Estimation of Chain Plates for Floodgates Working in Seawater by Continuum Fatigue-Creep Damage Theory and Transient Analysis of Diffusion Process of Hydrogen

Abstract:

Lifetime estimation of chain plates made of 45Cr high strength steel for floodgates working in seawater has been performed by considering fatigue-creep crack initiation and hydrogen assisted crack propagation at the plate. According to the records of operating history of the floodgates, average lifetime of the chain plate is in range of 18~22 years. Estimated lifetime of the chain plate by continuum fatigue-creep damage theory and transient analysis of the diffusion process of atomic hydrogen in the metallic lattice is in range of 19~25 years.

• Periodical: Advanced Materials Research (Volume 1095)
• Pages: 452-457
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1095.452
• Online since: March 2015
• Authors: Mun Chan Jong, Li Yang Xie, Hak Jin Song, Sun Jong Jon, Myong Il Kim, Xiao Lv
• Keywords: Fatigue-Creep Damage, Hydrogen Embrittlement, Stress Corrosion Cracking

References

[1] A. A. Oehlerta: Room temperature creep and the initiation of stress corrosion cracking in AerMet 100. Materials Forum, 1993, 17 (4): 415 ~429.

[2] A. A. Oehlerta: Room temperature creep of high strength steels. Acta Metallurgicaet Materialia, 1994. 42(5): 1493 ~4508.

[3] J. Cwiek: Hydrogen assisted cracking of high-strength weldable steels in sea-water, Journal of Materials Processing Technology, Elsevier, 164~165(2005), 1007~1013.

DOI: 10.1016/j.jmatprotec.2005.02.083

[4] E. Fallahmohammadi: Measurement of lattice and apparent diffusion coefficient of hydrogen in X65 and F22 pipeline steels, Int. J. of Hydrogen Energy, Elsevier, 38(2013), 2531~2543.

DOI: 10.1016/j.ijhydene.2012.11.059

[5] S. Serebrinski: A quantum-mechanically informed continuum model of hydrogen embrittlement, Journal of Mechanics and Physics of Solids, Elsevier, 52(2004), 2403~2430.

DOI: 10.1016/j.jmps.2004.02.010

[6] R. P. Gangloff: Hydrogen assisted cracking of high strength alloys, Comprehensive Structural Integrity, Vol. 6, Elsevier Science, New York, (2003).

[7] V. Olden: FE Simulation of Hydrogen Diffusion in Duplex Stainless Steel – Influence of Phase Shape, an Size and Embeded Deffects, Proceedings of the Twenty-third (2013).

[8] E. S. Mioara: Hydrogen Embrittlement of Ferrous Materials, Ph.D. thesis of Brussel University, Belgium, ( 2006), 143~176.

[9] C. Pan: Hydrogen Embrittlement induced by atomic hydrogen and hydrogen induced martensites in type 304L stainless steel, Materials Science and Engineering, Elsevier, A 351(2003), 293~296.

DOI: 10.1016/s0921-5093(02)00856-0

[10] T. Zhang: Study of correlation between hydrogen induced stress and hydrogen embrittlement, Materials Science and Engineering, Elsevier, A 347(2003), 291~295.

DOI: 10.1016/s0921-5093(02)00600-7

[11] L. J. Qiao: Prediction of threshold stress intensity factor for hydrogen induced intergranular cracking of tubular steels, Materials Science and Engineering, Elsevier, A 276(2000), 141~144.

DOI: 10.1016/s0921-5093(99)00444-x

[12] S. Kwofie, H. D. Chandler: Fatigue life prediction under conditions where cyclic creep-fatigue interaction occurs, International J. of Fatigue, Elsevier, 29(2007), 2117~2124.

DOI: 10.1016/j.ijfatigue.2007.01.022

[13] R. Rajendran, J. K. Paik: Creep life prediction of high strength steel plate, Materials and Design, Elsevier, 29(2008), 427~435.

DOI: 10.1016/j.matdes.2007.01.003

[14] K. Harry: Creep analysis, New York, John Wiley & Sons, (1980).

[15] L.F. Coffin Jr: J. Eng. Mater. Tech. ASME 76 (1954), 931.

[16] S.S. Manson: NASA Technical Note 2933, Cleveland, (1954).
