Precast Floor Plates from Lightweight Concrete

Abstract:

The paper deals with a system of precast floor plates from lightweight concrete intended mainly for building of family houses and residential construction. The developed system has two types of precast floor plates made from lightweight concrete: floor plates for floor systems and solid section floor plates. This paper describes solid section floor plates. The unambiguous advantage of lightweight concrete floor construction is weight lower by as much as 37% compared to floor structure made from common concrete, while bearing strength remains unchanged as well as high fire resistance. This type of floor slabs has also been successful in the system of assembled prefabricated houses thanks to its lower weight and elimination of the wet construction process.

• Periodical: Advanced Materials Research (Volume 1106)
• Pages: 152-155
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1106.152
• Online since: June 2015
• Authors: Michala Hubertová*, Pavel Hladík
• Keywords: Expanded Clay Aggregate, Lightweight Concrete, Prefabricated Floor Slabs

References

[1] url: www. liastrop. cz.

[2] ČSN EN 1990 Eurocode: Basis of structural design.

[3] ČSN EN 1991-1-1 Eurocode 1: Action on structures -Part 1-1: General actions – Densities, self-weight, imposed loads for buildings.

DOI: 10.3403/30396138

[4] CSN EN 1992-1-1 Eurocode 2: Design of concrete structures - Part 1-1: General rules and rules for buildings.

[5] CSN EN 13369 Common rules for precast concrete products.

[6] CSN EN 13747 Precast concrete products - Floor plates for floor systems.

[7] ČSN EN 13670 Execution of concrete structures.

[8] CSN 73 0532 Acoustics - Assessment of sound isolation in building construction and buildings - Requirements.

[9] CSN 73 0540-1 Thermal protection of buildings - Part 1: Terminology.

[10] CSN 73 0540-2 Thermal protection of buildings - Part 2: Requirements.

[11] CSN 73 0540-2 Thermal protection of buildings - Part 3: Design value quantities.

[12] CSN 73 0540-4 Thermal protection of buildings - Part 4: Calculation methods.

[13] Hladík a Chalivopulos s. r. o.: Structural calculation of solid section precast floor slabs from lightweight concrete.

[14] Hladík a Chalivopulos s. r. o.: Structural calculation of precast floor slabs from lightweight concrete for floor systems.

[15] Pavus a. s.: Certificate of classification of fire resistance No. PK2-03-10-004-C-0 Loadbearing floors and roofs with fire-separating function as per +A1: 2010 Article 7. 3. 3.

[16] Certificate of the test No. 397/10 Determination of thermal conductivity coefficient of lightweight concrete with lightweight aggregate Liapor at stabilized state. Accredited laboratory at UTHD FAST in Brno.

[17] Zach, J.: Report No. 09/09/1527 Calculation of sound insulating properties of solid section floor slabs from lightweight concrete LC 25/28 D1. 6. VUT FAST Brno (2009).

[18] Zach, J.: Report No. 09/10/Z1 Calculation of sound insulating properties of solid section floor slabs from lightweight concrete LC 25/28 D1. 6. VUT FAST Brno (2009).

[19] Zach, J.: Report No. 10/04/1592 Calculation of sound insulating and thermo-insulating properties of filigreed floors. VUT FAST Brno (2010).

[20] Hubertova, M., Technical manual Floor system Liastrop – basic data for designing. Lias Vintířov, LSM, k. s. 1. Edition (2010).
