Comparison of Two Methods for Testing the In-Plane Shear Property of 3D Stitched Plain Woven C/SiC Composites

Abstract:

Three types of three-dimensional stitched carbon fiber reinforced silicon carbide composites (3DS C/SiCs) with 4, 9 and 16 Z-yarn/cm² were fabricated by chemical vapor infiltration, respectively. Both iosipescu specimens without enough representative volume elements (RVEs) and ±45° tension specimens containing enough RVEs were tested to attain the in-plane shear properties of 3DS C/SiCs. The results showed that these two methods produced similar results. This demonstrated that the dimensions of iosipescu specimens were not necessary to cover enough RVEs for 3DS ceramic matrix composite in-plane shear testing. With respect to the shear modulus, both two methods would be regarded as the effective methods. However, in terms of the in-plane shear strength, iosipescu method would be a more reliable method.

• Periodical: Advanced Materials Research (Volume 1110)
• Pages: 3-6
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1110.3
• Online since: June 2015
• Authors: Hua Jie Xu*, Li Tong Zhang, Lai Fei Cheng
• Keywords: ±45° Tension Method, In-Plane Shear Property, Iosipescu Method, Stitched C/SiC

References

[1] I.W. Krenkel, in: Handbook of Ceramic Composite, edited by N.P. Bansal, chapter, 6, Kluwer Academic Publishers (2005).

[2] H. Xu, L. Zhang and L. Cheng: Mater. Des. Vol. 67 (2015), pp.428-35.

[3] R. Naslain: Compos. Sci. Technol. Vol. 64 (2004), pp.155-70.

[4] W.P. Keithand and K.T. Kedward: J. Am. Ceram. Soc. Vol. 80 (1997), pp.357-64.

[5] H. Xu, L. Zhang and L. Cheng: Mater. Des. Vol. 64 (2014), pp.434-40.

[6] H. Xu, L. Zhang, Y. Wang and L. Cheng: Ceram. Inter. Vol. 41 (2015), pp.283-90.

[7] H. Xu, L. Zhang and L. Cheng: Compos. Sci. Technol. Vol. 106 (2015), pp.120-6.

[8] W.R. Broughton, in: Mechanical Testing of Advanced Fibre Composites, edited by J.M. Hodgkinson, chapter, 6, CRC Press/Woodhead Publishing (2000).
