Development of an In Situ Tool Wear Monitoring System Using the Cutting Sound

Abstract:

This paper discusses the development of an in-situ, real-time tool wear monitoring system using the cutting sound that occurs during machining. In this study, the turning of carbon steel was implemented to examine the relationship between tool wear and the waveform of the cutting sound. Characteristic waveforms were extracted by fast Fourier transform (FFT) analysis of the cutting sound. The results indicated that the sound pressure of a specific frequency range increased during the progress of cutting-tool wear. In addition, it was possible to monitor the progress of tool wear by measuring the spectrum of a specific frequency range, even if the shape of the tool rest and the shapes of the work material were different, under certain cutting conditions.

• Periodical: Advanced Materials Research (Volume 1117)
• Pages: 277-280
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1117.277
• Online since: July 2015
• Authors: Haruka Takahashi*, Katsuhiko Sakai, Hiroo Shizuka
• Keywords: Cutting Sound, FFT, In Situ, Sound Pressure, Tool Wear

References

[1] Xiaoli Li A brief review: acoustic emission method for tool wear monitoring during turning, (International Journal of Machine Tool Manufacture 42 2002 257-165.

DOI: 10.1016/s0890-6955(01)00108-0

[2] Haruto MATSUMOTO, Tsukasa KONDO: study on distinction of cutting condition based on cutting sound– System development and examination, 46 (2007-9).

[3] Naohumi AOKI: Digital sound processing Introduction in Japanese, 2006, CQ Publication.
