Using Simulated Data to Support the Calibration Process of ED-XRF Analysis

Abstract:

In the general practice of ED-XRF measurements, the values of elemental concentrations are derived from complicated calculation methods. Hereby a simple mathematical formula is suggested, which provides an easy way to prepare standard samples. On the other hand, the simulation of spectral lines may also be a helpful tool for the calibration process. In this study, measured and simulated data were used for the quantitative analysis of ternary Au-Ag-Cu alloys. To determine the calibration points, the peak intensity ratio method was applied and the calibration curves were fitted. This work presents the results of a twofold investigation aimed at: a) finding a suitable computational tool to optimise the parameters of the underlying equations and b) testing the reliability of the simulated data to determine the concentrations of multi-element standard samples. Based on comparisons of calculated concentrations it can be stated that a simple calculation method with simulated data provides an easy tool to define calibration standards. It is also demonstrated that the parameters of the linear plots can be optimised to yield improved results.

• Periodical: Advanced Materials Research (Volumes 1120-1121)
• Pages: 1435-1440
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1120-1121.1435
• Online since: July 2015
• Authors: Dániel Koncz-Horváth*, Zoltán Gácsi
• Keywords: Energy Dispersive X-Ray Fluorescence, Genetic Algorithm, Intensity Ratios, Multi-Element Method, Spectrum Simulation

References

[1] F. Reilly, XRF for film thickness measurement: Pros vs. cons of common configurations: Choosing a benchtop or a hand-held X-ray fluorescence machine often boils down to user's specific needs, Metal Finishing 104 (2006) 20-24.

DOI: 10.1016/s0026-0576(06)80360-0

[2] R.P. Alvarez, A. Markowicz, D. Wegrzynek, E.C. Cano, S.A. Bamford, D.H. Torres, Quality management and method Validation in EDXRF analysis, X-Ray Spectrom. 36 (2007) 27-34.

DOI: 10.1002/xrs.923

[3] A. Tomoya, Analytical precision and accuracy in X-ray fluorescence analysis, The Rigaku Journal 21 (2004) 26-38.

[4] J.W. Criss, L.S. Birks, Calculation methods for fluorescent x-ray spectrometry. Empirical coefficients versus fundamental parameters, Analytical Chemistry 40 (1968) 1080-1086.

DOI: 10.1021/ac60263a023

[5] R.M. Rousseau, Fundamental algorithm between concentration and intensity in XRF analysis, X-Ray Spectrom. 13 (1984) 121-125.

DOI: 10.1002/xrs.1300130307

[6] R. Gullayanon, A calibration methodology for energy dispersive X-ray fluorescence measurements based upon synthetically generated reference spectra, PhD dissertation, Georgia Institute of Technology, (2011).

[7] M. Milazzo, C. Cicardi, Simple Methods for Quantitative X-Ray Fluorescence Analysis of Ancient Metal Objects of Archaeological Interest, X-Ray Spectrom. 26 (1997) 211-216.

DOI: 10.1002/(sici)1097-4539(199707)26:4<211::aid-xrs214>3.0.co;2-g

[8] Zs. Sándor, S. Tölgyesi, I. Gresits, M. Káplán-Juhász, Qualitative and Quantitative Analysis of Medieval Silver Coins by Energy Dispersive X-Ray Fluorescence Method, Journal of Radioanalytical and Nuclear Chemistry 246 (2000) 385-389.

DOI: 10.1023/a:1006755414703

[9] N. Ritchie, J.M. Davis, D.E. Newbury, DTSA-II: A New Tool for Simulating and Quantifying EDS Spectra - Application to Difficult Overlaps, Microscopy and Microanalysis, 14 (2008) 1176-1177.

DOI: 10.1017/s143192760808361x

[10] R. Leardi, Genetic algorithms in chemistry, J. of Chromatography A. 1158 (2007) 226-233.

[11] J.H. Holland, Adaptation in natural and artificial systems, The University of Michigan Press, Michigan (1975).

[12] Information on http: /www. cstl. nist. gov/div837/837. 02/epq/dtsa2.

[13] Zs. Sándor, I. Gresits, M. Káplán-Juhász, X-ray fluorescence analysis of medieval gold coins and jewellery, J. of Radioanalytical and Nuclear Chemistry, 256 (2003) 283-288.

DOI: 10.1023/a:1006755414703
