Advanced Active Prestressed CFRP in RCC Structures

Abstract:

. The need for rehabilitation of reinforced concrete structures is rapidly increasing. Fibre reinforced polymer (FRP) composite materials for concrete structures have high strength-to-weight ratios that can provide high prestressing forces while adding minimal additional weight to a structure. They also have good fatigue properties and exhibit low relaxation losses, both of which can increase the service lives and the load carrying capacities of reinforced concrete structures. Carbon fiber reinforced polymer (CFRP) composite system is integrated system based on carbon fibres and epoxy resins. By prestressing the CFRP laminates, the material is used more efficiently as a part of its tensile capacity is utilised and it contributes to the load bearing capacity under both service and ultimate load condition. This is an ideal technique as it combines the advantage of using noncorrosive and lightweight advanced composite material in the form of FRP laminates with high efficiency offered by external prestressing. An innovative mechanical anchorage system was developed to prestress the FRP laminates directly by jacking and reacting against the RCC structure.This paper describes the use of Prestressed CFRP laminates for strengthening of RCC structures including practical applications on slabs and bridges. Also it elucidates the post strengthening testing carried out for the validation of this technique.

• Periodical: Advanced Materials Research (Volume 1129)
• Pages: 290-297
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1129.290
• Online since: November 2015
• Authors: Gopal L. Rai
• Keywords: Bridges, FRP, Infrastructure, Prestressed, RCC, Retrofitting, Slab

References

[1] ACI 440. 2R-08, Guide for the design and construction of externally bonded FRP systems for strengthening concrete structures, American Concrete Institute (2008).

DOI: 10.14359/51700867

[2] Task group 9. 3 FRP reinforcement for concrete structures, Externally bonded FRP reinforcement for RC structures, fib CEB-FIP, Technical report bulletin 14(2001).

DOI: 10.35789/fib.bull.0014.ch01

[3] R. Irwin and A. Rahman, FRP strengthening of concrete structures – Design constraints and practical effects on construction detailing, New Zealand Concrete Society Conference 2002., Section. 4 Paper 2 (2002).

[4] S.A. Sheikh and Y. Li, Design of FRP confinement for square concrete column, Engineering Structures 29 (2007) 1074–1083.

DOI: 10.1016/j.engstruct.2006.07.016

[5] E. Grande, M. Imbimbo and E. Sacco, A simple model for evaluating the structural response of masonry structures strengthened with FRP, The 14th World Conference on Earthquake Engineering, October 12 – 17, Beijing, China (2008).

[6] Mandara. M, Piazza. M, Perdikaris. P and Schaur. C, Repairing and strengthening for new requirements: Use of Mixed Technologies, Improving Buildings Structural Quality by New Technologies Seminar, Lisbon (2002).

[7] R. El-Hacha, R. G. Wright and M. F. Green, Prestressed fiber-reinforced polymer laminates for strengthening structures, Prog. Struct. Engng Mater. 2001., vol. 3, pp.111-121, (2001).

DOI: 10.1002/pse.76

[8] R. El-Hachaand M. Y. E. Aly, Anchorage system to Prestress FRP Laminates for flexural strengthening of Steel-concrete composite girders, Journal of Composites for Construction © ASCE ( 2013). Vol17, pp.324-335.

DOI: 10.1061/(asce)cc.1943-5614.0000323

[9] Dr. G.L. Rai, Pre-stressing Techniqiues for structural strengthening using FRP composites, The Masterbuilder, May 2013, pp.200-202 (2013).

[10] G.L. Rai and A.N. Bambole , Strengthening of bridge by Pre-Stressing at JNPT and testing its efficacy, ACI Fall 2010 Convention ACI SP 285 (2010).

DOI: 10.14359/51683927
