The Rack-Pinion Gearing for High Order of Contact

Abstract:

After an extensive research on the fundamental theory, the theoretical basis for the gearing with equal conjugate curvature is presented in this paper. This includes the theory for gear meshing with high oder of contact. In comparison to previous studies, the theory of this paper is more restricted going beyond third order parameters into the fourth order, the teeth profile had one order of contact higher than that of the ordinary gearing. So that further improved the contact strength of tooth profile. A large category of gearings with high order of contact was presented. The rack-pinion gearing with equal conjugate curvature is one of them. In my gearing the curvature center of media rank extend along the pitch line continuously and steadily.

• Periodical: Advanced Materials Research (Volumes 129-131)
• Pages: 1083-1087
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.129-131.1083
• Online since: August 2010
• Authors: Hu Ran Liu
• Keywords: Conjugate, Gear, Meshing, Rack

References

[1] F. Neumann, Machine Element, Elsveir Press. 1990 London.

[2] Komori T, Arga Y, Nagata S (1990) A new gear profile having zero relative curvature at many contact points. Trans ASME 12(3): 430~436.

DOI: 10.1115/1.2912626

[3] Komori T, (1988) A new gear profile of relative curvature being zero at contact points. Proceeding of International Conference on gearing, China CMCC,.: 230~236.

[4] Xiangying, Feng; Aiqun Wang lee, Linda; (2004)( Study on the design principle of the Logix gear tooth profile and the selection of its inherent parameters. International Journal of Advanced Manufacture Technology Dec. Vol 24. (11/12): 789~794.

DOI: 10.1007/s00170-003-1741-8

[5] Li.F. (2002 ) Study for the forming principle of Logix gear tooth profile and its mesh performance Journal of Xiamen University, vol36(1): 12-16.
