Study on Static Characteristics of an Integrated Six-Axis Accelerometer Based on Parallel Mechanism

Abstract:

It is difficult to fabricate one sensing element to simultaneously sense three linear acceleration components and three angular acceleration components, so as to find rare reports on six-axis accelerometer. The aim of this on-going project was to research an integrated six-axis accelerometer using parallel mechanism as the structure for sensing element. In order to optimize so many parameters, the paper defined the important static characteristic indices, analyzed the relationship between indices and structural parameters of sensing element. Based on the definition of the indices, the structural parameters were designed by the physical model of solution space. Finally, FEM simulation experiment is carried out to verify effectiveness of the method.

• Periodical: Advanced Materials Research (Volumes 129-131)
• Pages: 224-229
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.129-131.224
• Online since: August 2010
• Authors: Chun Zhan Yu, Xin Yi Zhang, Jin Hong Han, Li Chao Tian
• Keywords: Isotropy Index, Parallel Mechanism, Six-Axis Accelerometer, Static Characteristic

References

[1] Ming Meng, Zhongcheng Wu, Yong Yu, et al: Design and Characterization of a Six-axis Accelerometer, Proceedings of the 2005 IEEE International Conference on Robotics and Automation, Barcelona, pp.2356-2361, April (2005).

DOI: 10.1109/robot.2005.1570465

[2] Ranjith Amarasinghe, Dzung Viet Dao, Toshiyuki Toriyama, et al: Development of Miniaturized 6-axis Accelerometer Utilizing Piezoresistive Sensing Elements, Sensors and Actuators A: Physical, vol. 134, no. 2, pp.310-320, March (2007).

DOI: 10.1016/j.sna.2006.05.044

[3] Gang Yuan, Dai-Hua Wang, Xiang-Hong Hou and Yan Zhao: Rapid Prototyping of a piezoelectric Six-Axis Accelerometer, Proceedings of the 7th World Congress on Intelligent Control and Automation, Chongqing, pp.2723-2726, June (2008).

DOI: 10.1109/wcica.2008.4593354

[4] R. M Murry., Zexiang Li, and S.S. Sastry, Mathematical Introduction to the Robot Manipulation, Beijing: China Machine Press, 1998, pp.76-81.

[5] Huang Tian, and Wang Jinsong: Closed Form Solution to The Local Dexterity and Isotropy of Stewart Parallel Manipulators, Chinese Journal of Mechanical Engineering, vol. 35, no. 5, pp.41-46, October (1999).

[6] Yang Jihou, and Gao Feng: The Physical Model of Solution Space and Performance Atlases of Four-bar Mechanism, Beijing: China Machine Press, 1989, pp.1-5.

[7] Chunzhan Yu, Xinyi Zhang, Qingxuan Jia, et al: Theoretical Research on a Six-axis Accelerometer for Humanoid Robot Wrist, Proceedings of the 2009 International Conference on Mechatronics and Automation, Changchun, pp.1411-1416, August, (2009).

DOI: 10.1109/icma.2009.5246662
