Research of Stress Transfer Area and its Length Prediction of Single-Lap Adhesive Joint

Abstract:

obtaining the law of stress and strain distribution of loaded adhesive joint has significant implication for joint design and its strength prediction. The dynamic FEM model of uniaxial tensile adhesive joint was established, in which strain fracture criteria is adopted. It can be observed from the FEM results that: lapped area of the joint bears shear stress primarily, the adherend areas located away from the lapped area bear steady tensile stress mainly and the adherend areas adjacent to lapped area endure tensile and shear stress simultaneously. Based on stress distribution characters, the joint was divided into three areas (lapped area, stress transfer area and uniform stress area) and an analytical model predicting the length of stress transfer areas was developed. DIC technology was applied to measure the whole field strain of the joint. It can be seen from the DIC results that the joints area division and the model of predicting the length of stress transfer length are feasible.

• Periodical: Advanced Materials Research (Volumes 129-131)
• Pages: 680-685
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.129-131.680
• Online since: August 2010
• Authors: Wei Ping Ouyang, Jian Ping Lin, Zhi Guo Lu
• Keywords: Digital Image Correlation (DIC), Single-Lap Adhesive Joints, Strain Field, Stress Transfer Area

References

[1] Kimberley Gilles, Making joints with structural adhesives, Welding Design& Fabrication, 2006: 24.

[2] Shu Guo, David A. Dillard, Raymond H. Plaut. Effect of boundary conditions and spacers on single-lap joints loaded in tension or compression. International Journal of Adhesion & Adhesives; (2006).

DOI: 10.1016/j.ijadhadh.2005.09.005

[3] Wooley GR, Carver DR. Stress concentration factors for bonded lap joints. J Aircraft 1971; 8: 817-20.

DOI: 10.2514/3.44305

[4] M-P Moutrille, K. Derrien, D. Baptiste, et al. Through-thickness strain field measurement in a composite/aluminium adhesive joint. Composites; (2009).

DOI: 10.1016/j.compositesa.2008.04.018

[5] Tsai MY, Morton J. An evaluation of analytical and numerical solutions to the single-lap joint. Int J Solids Struct 1994; 31(18): 2537-63.

DOI: 10.1016/0020-7683(94)90036-1

[6] Tsai MY, Oplinger DW, Morton J. Improved theoretical solutions for adhesive lap joints. Int J Solids Struct 1998; 31(12): 1163-85.

DOI: 10.1016/s0020-7683(97)00097-8

[7] Chang-Su Ban, Young-Hwan Lee, et al. Strength prediction of adhesive joints using the modified damage zone theory. Composite Structures; (2008).

DOI: 10.1016/j.compstruct.2008.03.016

[8] A. Haque, A. Ramasetty. Theoretical study of stress transfer in carbon nanotube reinforced polymer matrix composites. Composite Structures; (2005).

DOI: 10.1016/j.compstruct.2004.09.029

[9] Golland M, Reissner E. The stresses in cemented joint. J Appl Mech 1944; 11: A17-27.

[10] L. Goglio，M. Rossetto，E. Dragoni. Design of adhesive joints based on peak elastic stresses. International Journal of Adhesion & Adhesives; (2008).

DOI: 10.1016/j.ijadhadh.2008.04.001

[11] Wim Van Paepegem, Assen A. Shulev, et al. Study of the deformation characteristics of window security film by digital image correlation techniques. Optics and Lasers in Engineering; (2009).

DOI: 10.1016/j.optlaseng.2008.03.005
