Simulation of Hybrid Electrical Vehicle Automated Mechanical Transmission Control System

Abstract:

For developing motor driven automated mechanical transmission of hybrid electrical vehicle, adjust and control the gear selecting motor, the gear shifting motor and the clutch motor. In the research of position-PID controller and robust disturbance observer, an automated mechanical transmission system based on position-PID was given. With Matlab, the position-PID controlling arithmetic and the controlling system models of the motors were built. Experimental results show that, a highly efficient and reliable automated mechanical transmission motor control system was developed.

• Periodical: Advanced Materials Research (Volumes 129-131)
• Pages: 7-11
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.129-131.7
• Online since: August 2010
• Authors: Jin Dong Zhang, Gui He Qin, Yong Ping Huang, Xiao Long Zhang
• Keywords: Automated Mechanical Transmission, Intelligent Control, Model, Robust, Simulation

References

[1] X. L. Hu, Multi-objective optimization of HEV fuel economy and emissions using evolutionary computation, SAE 2004 World Congress and Exhibition, 2004-01-1153.

DOI: 10.4271/2004-01-1153

[2] H. D. Lee, S. K. Sul, H. S. Cho, Advanced gear-shifting and clutching strategy for a parallel-hybrid vehicle, IEEE Industry Applications Magazine, Vol. 6, 2000, pp.26-32.

DOI: 10.1109/2943.877837

[3] M. Ye, D. T. Qin, Z. J. Liu Jixie, Regenerative braking control strategy in mild hybrid electric vehicle equipped with automatic mechanical transmission, Gongcheng Xuebao/Chinese Journal of Mechanical Engineering, Vol. 42, 2006, pp.156-160.

DOI: 10.3901/jme.2006.10.156

[4] D. Z. Wang, R. Y. Tang, J. Yang, HEV control system based on adaptive hierarchical supervisory control strategy, 2004 5th Asian Control Conference, 2004, pp.283-287.

[5] G. H. Qin, A. L. Ge, H. S. LI, On-board fault diagnosis of automated mechanical transmission control system, Transactions on Control Systems Technology, Vol. 12, 2004, pp.564-568.

DOI: 10.1109/tcst.2004.825133

[6] P. Aravindan, M. Punniyamoorthy, Justification of advanced manufacturing technologies (AMT), International Journal of Advanced Manufacturing Technology, Vol. 19, 2002, pp.151-156.

DOI: 10.1007/s001700200008

[7] E. Andreas, T. Savvas, A. Antonios, Strategic planning, transfer and implementation of Advanced Manufacturing Technologies (AMT), Technovation, Vol. 22, 2002, pp.201-212.

DOI: 10.1016/s0166-4972(01)00024-4

[8] M. Taniguchi, Instability of planar traveling waves in bistable reaction-diffusion systems, Discrete and Continuous Dynamical System, Vol. 1, 2003, pp.21-44.

DOI: 10.3934/dcdsb.2003.3.21
