Finite Element Numerical Simulation of EDM Surface Strengthening in Gas Medium of Stainless Steel 1Cr13

Abstract:

In this paper, the finite element simulation model of the electrode melting drops coating process on the workpiece was established, and the numerical simulation of the the temperature field and thermal stress field of the single-pulse electric spark discharge strengthening region was carried out. The results indicated that, in the initial moment of spark discharge, the heat-affected region was small, but the temperature gradient and the maximum temperature were very big. With time increased, heat-affected region kept growing, while the temperature gradient and the maximum temperature both kept decreasing. The extrusion stress mainly concentrated in the region of the outer edge of the combination area of the coating point and the workpiece, and the region of the coating point surface. The tensile stress mainly concentrated in the region of the combination area of the coating point and the workpiece. As time increased, both maximum stress and stress gradient kept growing. The results showed that the experimental data by X-ray stress test had good agreement with the simulation results.

• Periodical: Advanced Materials Research (Volume 136)
• Pages: 189-193
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.136.189
• Online since: October 2010
• Authors: H.X. Wang, X. Zhang, W.S. Zhang
• Keywords: EDM Surface Hardening, Finite Element Analysis (FEA), Prediction Model, Stress Field, Temperature Field

References

[1] Murali.M. S, Yeo.S. H: Japan Journal of Applied PhysicsbVol. 44 (2005), pp.5254-5263.

[2] Yeo.S. H, Kurnia. W and Tan.P. C: Applied Physics Vol. 40(8) (2007), pp.2513-2521.

[3] Das. S, Koltz. M and Klocke. F: Journal of Materials Processing Technology Vol. 142(2003), pp.434-451.

[4] Lasagni. A, Soldera. F and Mucklich. F: Modeling and Simulation in Materials Science and Engineering Vol. 12(2004), pp.835-844.

[5] Rebelo J C, et al: Materials Science Forum Vol. 404-407 (2002), pp.159-164.

[6] M.R. Patel, M.A. Barrufet and P.T. Eubank: The Anode Erosion Model. Appl. Phys Vol. 66 (1989), No. 9, pp.4104-4111.

[7] P.T. Eubank, M.R. Patel, M.A. Barrufet, et al: Appl. Phys Vol. 73(1993), No. 9, p.7900.

[8] Ikai T, Hashigushi K: Switzerland Proceedings of International Symposium for Electro Machining. Vol. 3(1995), pp.163-170.

[9] Shupeng. Su: Study on the Proeess and Mechanism of Electrieal Discharge Milling Based on Gas Dielectric. PhD Dissertation. Shandong University (2008).

[10] T. Zhen, G.W. Guo: Thermophysical Properties of Engineering Alloys (Metalluegical Industry Press, China 1994).
