Experiment Research of Cutter Edge and Cutting Parameters Influence on Machined Surface Roughness for High Speed Milling Hardened Steel

Abstract:

By using experiment cutter edge topography obtained by super depth three-dimension microscope, fits the cutter edge curve and calculate experiment cutter edge radius value; by high speed milling hardened steel experiment, individually researches cutter edge and cutting parameters influence on machined surface in high speed milling hardened steel with end-milling cutter and ball-end milling cutter. The experiment analysis results show that under the same cutting parameters condition, machined surface roughness in high speed end-milling cutter milling is better than in high speed ball-end milling; within experiment selected cutting parameter range, cutter edge radius is the main influence factor on machined surface roughness in high speed end- milling hardened steel, while the influence on machined surface roughness in high speed ball-end milling hardened steel is not obvious. In end-milling, when edge radius and milling depth are in the same order magnitude or the difference is not obvious, milling depth should be a little bigger than selected cutter edge radius value.

• Periodical: Advanced Materials Research (Volume 136)
• Pages: 86-90
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.136.86
• Online since: October 2010
• Authors: Wei Zhang, Min Li Zheng, Ming Ming Cheng, Quan Wan
• Keywords: High Speed Turning, Optimization, Surface Roughness (SR), Titanium Alloy Membrane Disc

References

[1] X.X. YIN and F.J. Wu: J. Modern Manufacturing Engineering (2009)No. 7, p.144.

[2] X.C. Liang and X.G. Zheng: J. Chinese Journal of Mechanical Engineer Vol. 37 (2001), p.109.

[3] Dominguez H. and Alvarez R. Proceedings of the 2001 IEEE International Conference on Control Applications Vol. 27 (2002), p.144.

[4] M.H. Deng and N. Ying: J. Tool Engineering Vol. 38(2004), p.25.

[5] C.K. Toh: J. Journal of Sound and Vibration Vol. 58 (2003), p.321.

[6] C.K. Toh: J. Material and Design Vol. 27(2004), p.107.

[7] C.K. Toh: J. Material and Design Vol. 30(2004), p.41.

[8] Y. WANG and H.H. HUANG: Journal of Central South University Vol. 40(2009), p.1604.

[9] Z.Q. Liu and Y. Wan: J. Machinery Manufacturing Engineer Vol. 12(2002), p.10.
