Integrated Design of Micro Configuration and Macro Arrangement with Scale-Coupled Effect for Maximum the Fundamental Frequency

Abstract:

It is well known that structural behaviors of composite solids are determined by topology of microstructures of different sizes. In this paper a concurrent topology optimization method for integrated design of materials and structures with periodical microstructure was presented. The microstructures were assumed to be uniform in macro scale and heterogeneous in micro scale and the optimization object was to maximize the material fundamental frequency. Design variables for structure and material microstructures were defined, independently. RAMP (Rational Approximation ofMaterial Properties) was adopted to ensure clear topologies in both macro and micro scales. Design variables for structure and material microstructures were integrated into one system by using the super-element method. Influences of Representative Volume Element sizes, the microstructure configuration and macro arrangement are investigated. Numerical experiments validate the proposed method which can be used as an innovative design concept for the lightweight structures.

• Periodical: Advanced Materials Research (Volumes 146-147)
• Pages: 1154-1158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.146-147.1154
• Online since: October 2010
• Authors: Yuan Dong Liu, Yi Hui Yin
• Keywords: Concurrent Optimization, Fundamental Frequency, Representative Volume Element (RVE), Scale Effect, Topological Optimisation

References

[1] Bensoussan A, Lions JL, Papanicolaou G. Asymptotic Analysis for Periodic Structures. Amsterdam: North Holland, (1978).

[2] Sigmund O. International Journal of Solids and Structure, 1994, 31(17): 2313~2329.

[3] Sigmund O. Mechanics of Material, 1995, 20: 351~368.

[4] Pedersen P. Structural and Multidisciplinary Optimization, 19: 169-182.

[5] Rodrigues H, Guedes JM, Bendsoe MP. Structural and Multi- disciplinary Optimization, 2002, 24: 1~10.

[6] Zhang Weihong, Sun Shiping. Chinese Journal of Theoretical and Applied Mechanics, 38(4): 522-529. (in Chinese).

[7] Sutherland LS, Shenoi RA, Lewis SM. Composites Science and Technology, 1999, 59: 209~220.

[8] Pecullan S, Gibiansky LV, T Journal of the Mechanics and Physics of Solids, 1999, 47: 1509~1542.

[9] Yan Jun. Multiscale Analysis and Concurrent Optimization for Ultra-Light Metal Structures and Materials. Ph. d Thesis, Dalian, 2007(in Chinese).

[10] Sigmund O. Journal of the Mechanics and Physics of Solids. 2000, 48: 397~428.
