Investigation of Temperature and Deformation of Mold Copper Plate in Slab Continuous Casting

Abstract:

Based on the cooling parameters of the mold copper plate for slab continuous casting in a steelmaking plant, the three-dimensional calculating model of the copper plate was established, and three-dimensional distributions of temperature, thermal stress and strain were simulated numerically by using finite element method (FEM). The maximum deformation of the mold copper plate, the highest temperature and thermal stress were obtained. This research is useful for the structure design of the mold.

• Periodical: Advanced Materials Research (Volumes 146-147)
• Pages: 1642-1645
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.146-147.1642
• Online since: October 2010
• Authors: Xing Zhong Zhang, Zheng Yi Jiang, Chun Xia Dou, Qiang Zhang
• Keywords: Mold Copper Plate, Slab Continuous Casting, Temperature, Thermal Deformation, Thermal Stress

References

[1] Feng Ke, Han Zhiwei, and Mao Jinghua: Foundry Technology, vol. 28(2007), p.135–138.

[2] Yang Gang, Li Baokuan, and Yu Yang: Acta Metallurgica Sinica, vol. 43(2007), p.332–336.

[3] Liu Xudong and Zhu Miaoyong: Acta Mettallurgica Sinica, vol. 42(2006), p.1137–1142.

[4] Wang Tiangang, Wang Baofeng, and Dong Fang: Continuous Casting, 4(2009), p.10–14.

[5] Long Xuesong and Peng Xianghe: Iron and Steel, vol. 41(2006), p.35–38.

[6] Liu Mingyan, Li Ping: Slab Continuous Caster, Beijing: Mechanical industry press, (1990).

[7] Sun Jiquan, Liu Qingguo. Heat Transfer, Harbin: Northeat Forestry Univeristy Press, (1997).
