Process Control of Injection Molding Based on Multiscale Visualization Methodology - A Case Study
Multiscale visualization approaches are proposed to efficiently assist designers not familiar with statistical mathematics in determining the optimal process parameter schemes for achieving desired part quality in injection molding, based on which the parameters’ relative importance to part quality and their influence on either single quality index or comprehensive part quality can be visually described by the map of the sum of squared deviations, response surface diagram and distribution map of comprehensive part quality. The proposed visualization approaches are universal for analyzing the effects of process parameters on the quality of any injection-molded plastic parts although the mobile phone cover is utilized as an example in the presentation of our work.
Zhengyi Jiang, Xianghua Liu and Jinglong Bu
J. Cheng et al., "Process Control of Injection Molding Based on Multiscale Visualization Methodology - A Case Study", Advanced Materials Research, Vols. 154-155, pp. 1839-1845, 2011
