Behavior of Four-Line High-Speed Railway Bridge with Two Main Trusses and K-Shaped Brace

Abstract:

Taking Jinan Yellow River Bridge as an example, using 3D finite element method, displacement and behavior of four-line high-speed railway bridge with two main trusses, K-shaped brace and middle suspender is studied. The results show that transversal wave of displacement of floor system is significant, and the difference of the displacement in transversal direction reaches 6 mm. The causes includes: large distance between two main trusses, large stiffness of stringers, longitudinal stiffeners and crossbeams, weak transversal stiffeners which do not connect to lower chords. About 90% of the loads are transferred to the crossbeam through path 1 and about 60% to 80% of these loads through K-shaped braces. Less than 10% of the loads transferred to lower chords through path 2.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 148-152
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.148
• Online since: December 2010
• Authors: Jiong Liang, Mei Xin Ye
• Keywords: Deformation Behavior, Four-Line High-Speed Railway, Steel Bridge, Two Main Trusses

References

[1] GAO Zong-yu: Large-span high-speed railway bridges across Yangtze River and Yellow River. Engineering Sciences Vol. 11-1 (2009), pp.17-21 (In Chinese).

[2] HOU Wen-qi, YE Mei-xin: Experiments on the mechanical characteristic of the integral steel orthotropic bridge deck with three main trusses of Nanjing Dashengguan Yangtze River Bridge. Journal of Railway Science and Engineering Vol. 5-3 (2008).

[3] ZHANG Ye-zhi, ZHANG Min: Study on horizontal bending of crossbeams of high-speed railway stringer-crossbeam composite floor system. Journal of the China Railway Society Vol. 32-1 (2010), p.59 (In Chinese).

[4] QIAN Zhu, DAI Gong-lian: Finite element analysis of integral joint in three-truss continuous steel truss arch bridge. Technological Development of Enterprise Vol. 28-7 (2009), p.54 (In Chinese).

[5] XIAO Hai-zhu, XU Wei, GAO Zong-yu: Design of Anqing Changjiang River Railway Bridge. Bridge Construction Vol. 2009-5 (2009), p.6 (In Chinese).

[6] Rail construction.

[2005] 140: Temporary code for design of newly-built passenger dedicated railways with speed of 200~250 kilometers per hour. (2005) (In Chinese).

[7] ZHANG Min, YE Meixin, ZHANG Yezhi: The mechanical behavior of steel orthotropic monolithic deck system with dense transverse girder. China Railway Science Vol. 31-3 (2010), p.28 (In Chinese).
